2. Zone Configuration

2. Zone Configuration
The information contained in this section will determine how each of the zones connected to the alarm
panel will respond, what report codes are to be transmitted and if cross zoning will be a factor. There
are two methods a zone may be programmed. Zones may be programmed individually (Standard) or by
the use of Zone Templates (Pre-Defined). Zone Templates should be used to reduce programming time.
Example, If there are 25 Perimeter Instant zones connected to the system that share the same
characteristics, programming a Perimeter Instant zone template and then applying that
zone template to each zone saves you from answering 19 additional programming prompts for each zone.
W a r n i n g : Programming Zone Templates must be completed first should you decide to use templates. W a r n i n g :
2 . 1 S t a n d a r d ( P r e - D e f i n e d = 2 . 1 S t a n d a r d ( P r e - D e f i n e d =
No) No)
PRE-DEFINED ?
NO
This option determines if the zone being programmed will have all the characteristics
programmed individually (Pre-Defined = No) or if you choose to use a Zone Template
(Pre-Defined = Yes). Go to menu 2.2 should you wish to select Zone Templates.
2.1.1 Zone Type
Z-## TYPE 2
(SCROLLING)
Select the appropriate Zone Type as required.
(see page 20 for a description of the available Zone Types and their characteristics).
2.1.2 Loop Type
Z-## TYPE 3
(SCROLLING)
Select the appropriate Loop Type as required.
(see page 20 for a description of the available Loop Types and their characteristics).
2.1.3 Report Codes
Zones are capable of transmitting Alarm, Trouble, Bypass, Cancel, and Restore report
codes. Select the report codes as required or if for an example, you do not wish to transmit
Restore codes, do not even go to that memory location, skip over it.
If you intend to use Ademco Contact ID or SIA format, any entry is acceptable other than 00.
(See Contact ID-SIA-Hex report code options on page 42 & 43 / 3.8 Receiver Routing Option).
2.1.3.1 Alarm
ALARM CODE
CODE NO
Select the alarm report code that will be transmitted to the central station.
(see Contact ID / SIA note in 2.1.3).
2.1.3.2 Trouble
TROUBLE CODE
CODE NO
Select the trouble report code that will be transmitted to the central station.
(see Contact ID / SIA note in 2.1.3).
2.1.3.3 Bypass
BYPASS CODE
CODE NO
Select the bypass report code that will be transmitted to the central station after the exit delay
has expired and the SMDC has been armed. (see Contact ID / SIA note in 2.1.3).
2.1.3.4 Cancel
CANCEL CODE
CODE NO
Select the Cancel report code that will be transmitted to the central station after an alarm
condition occurs and the system has been disarmed within two minutes of the alarm activation.
(see Contact ID / SIA note in 2.1.3).
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839
Selections: Yes / No
Default: No
Selections: See Table 1: Zone Types
Default: Type 2
Selections: See Table 2: Loop Types
Default: Type 3
Selections: 01-FF / Contact ID / SIA
Default: No Report
Selections: 01-FF / Contact ID / SIA
Default: No Report
Selections: 01-FF / Contact ID / SIA
Default: No Report
Selections: 01-FF / Contact ID / SIA
Default: No Report
SMDC-16 Program Manual
2. Zone Configuration
(Set Zone #)
1. Zone Config.
1. Zone Type
2. Loop Type
3. Report Codes
1. Alarm
2. Trouble
3. Bypass
4. Cancel
5. Restore
4. Zone Name
5. Loop Response
6. Entry Delay
7. Zone Features
1. Silent Day/
Audible Night
2. Telephone
3. Radio
4. Bypass Allowed
5. Shunt Allowed
6. Display Armed
7. Walk Test
8. Monitor Mode
9. Auto Walk at Arm
8. Zone Outputs
1. Bell 1
2. Bell 1 Pulse
3. Bell 2
4. Bell 2 Pulse
5. Relay 1
6. Relay 2
7. PGM 1
8. PGM 2
9. PGM 3
9. Alarm Verify
2. Templates
(Set Zone Type)
1. Loop Response
2. Zone Features
1. Silent Day/
Audible Night
2. Telephone
3. Radio
4. Bypass Allowed
5. Shunt Allowed
6. Display Armed
7. Walk Test
8. Monitor Mode
9. Auto Walk at Arm
3. Zone Outputs
1. Bell 1
2. Bell 1 Pulse
3. Bell 2
4. Bell 2 Pulse
5. Relay 1
6. Relay 2
7. PGM 1
8. PGM 2
9. PGM 3
3. Cross Zone Pairs
1. Cross Zone Pair 1
1. Zone A
2. Zone B
2. Cross Zone Pair 2
1. Zone A
2. Zone B
3. Cross Zone Timer
4. # of Shunt Alarms
5. Shunt Period
6. # of Expander Bds.
3440-0252 A4
