Optex SMDC-16 Programming Manual page 59

0. Pager - Fax - Printer Options 0. Pager - Fax - Printer Options
0 . 2 F a x O p t i o n s 0 . 2 F a x O p t i o n s
This selection details the programming options for the transmission of the history
buffer to a fax machine. The volume of history transmitted will depend on the usage
of this option. The first history event that will be sent to the fax will be the first
event after the last event sent previously. Note: External modem required for fax option.
0.2.1 Fax Telephone Number
FAX TELEPHONE #
00000000000000000
Select up to 16 digits/characters for the telephone and any required delays or
access codes. (see dialer chart below).
Dialer Chart
Selections:
Instant Key
Memory Key = 5 second dial tone detect (appears as a ";")
Stay Key
Away Key
0.2.2 Modem Command
MODEM COMMAND
(BLANK)
Select up to 16 digits/characters for the modem command (initialization string)
using numeric and the alphabet table on page 19.
0.2.3 Fax Class 2.0
FAX CLASS 2.0
NO 0=NO 1=YES
Select the modem class by entering either:
Yes = class 2.0 / No = class 2
N o t e : consult your modem manual to determine the class. N o t e :
0.2.4 Fax Time
TIME HH:MM
__:__ AM 1=PM
Select the time of day the SMDC will transmit the entire history buffer to the
fax machine. (see 0.2.5-Fax Schedule).
0.2.5 Fax Schedule
FAX SCHEDULE
(SCROLLING)
Select the regularity the alarm panel will transmit the history to the fax machine.
Your options are:
0 . 3 P r i n t e r O p t i o n s 0 . 3 P r i n t e r O p t i o n s
0.3.1 Printer Enabled
PRINTER ENABLED
NO 0=NO 1=YES
This options determines if the alarm panel will be transmitting the events to the on site printer.
0.3.2 Logging Options
LOGGING OPTIONS 0
(SCROLLING)
This options determines the type of events the alarm panel will be transmitting to the on site printer.
Your options are:
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual
Selections: 0-9 : ; # *
Default: 00000000000000000
= 0 through 9
= 3 second dial pause (appears as a ":")
= # (pound)*
= * (asterisk)
Selections:
Default: Blank
Selections: Yes / No
Default: No
Selections: 12:00am - 11:59pm
Default: 12:00am 1=pm
0 Selections: 01-03
Default: 0
1. Daily.
2. Weekly (Sunday only).
st
3. Monthly (1 day of month).
Selections: Yes / No
Default: No
Selections: 01-03
Default: 0
01. All occurrences.
02. Alarm occurrences.
03. Open and Close occurrences.
0. Pager-Fax-Printer
59 of 59
1. Pager Options
1. Telephone Number 1
2. Telephone Number 2
3. Pager Delay
4. Alarm Report
5. Open/Close Report
6. Open/Close Fail Rpt
7. System Report
2. Fax Options
1. Fax phone Number
2. Modem Command
3. Fax Class 2.0
4. Fax Time
5. Fax Schedule
1. Daily
2. Weekly
3. Monthly
3. Printer Options
1. All Events
3440-0252 A4
