3. Receivers 3. Receivers
R e c e i v e r I n f o r m a t i o n R e c e i v e r I n f o r m a t i o n
All central station receivers have different types of line cards that are capable of accepting or not accepting certain formats. Therefore it is recommended
that you contact the technical support group at your central station to determine the fastest and most reliable format available.
# Format Name
1 10PPS 3-1 10 pulses per second - 3 digit account number - 1 digit report code
2 10PPS 3-1 EXT 10 pulses per second - 3 digit account number - 1 digit report code w/ extended 2 digit
3 10PPS 4-1 10 pulses per second - 4 digit account number - 1 digit report code
4 10PPS 4-1 EXT 10 pulses per second - 4 digit account number - 1 digit report code w/ extended 2 digit
5 10PPS 4-2 10 pulses per second - 4 digit account number - 2 digit report code
6 20PPS 3-1 20 pulses per second - 3 digit account number - 1 digit report code
7 20PPS 3-1 EXT 20 pulses per second - 3 digit account number - 1 digit report code w/ extended 2 digit
8 20PPS 4-1 20 pulses per second - 4 digit account number - 1 digit report code
9 20PPS 4-1 EXT 20 pulses per second - 4 digit account number - 1 digit report code w/ extended 2 digit
10 20PPS 4-2 20 pulses per second - 4 digit account number - 2 digit report code
11 40PPS W/PARITY 40 pulses per second - 3 digit account number - 1 digit report code
12 VAR FSK 4-2 Tones (no pulses)
13 SIA LEVEL 1 Tone (no pulses)
14 CONTACT ID Tone (no pulses)
R e c e i v e r R o u t i n g O p t i o n s R e c e i v e r R o u t i n g O p t i o n s
The chart below indicates all reporting options in alphabetical order and the individual receiver routing.
Report Codes
2-Wire Smk Alarm
2-Wire Smk Restore
2-Wire Smk Trbl
Abnormal Self Test
AC Fail
AC Restore
Auto Arm Code
Auto Arm Fail
Aux. Power Fail
Aux. Power Restore
Battery Low
Battery Restore
Bell Fault Restore
Bell Fault Trouble
Bell Restore
Box Tamper
Box Tamper Restore
Bus Fault
Bus Restore
Close Code (all)
Close Code (user)
Close Exception
Comm Fail
Duress
Legend
3.8.1 = Alarm Codes /
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839
- 4 digit account number - 2 digit report code
- 4 digit account number - zone type w/zone number in English
- 4 digit account number - zone type w/zone number in English
Menu Rcvr
Routing
4.6.1 3.8.1.
4.6.3 3.8.1.
4.6.2 3.8.1.
1.3.5 3.8.3.
5.1.1 3.8.3.
5.1.2 3.8.3.
8.3.2 3.8.2.
8.3.3 3.8.2.
5.3.4 3.8.3.
5.3.5 3.8.3.
5.1.3 3.8.3.
5.1.4 3.8.3.
5.1.8 3.8.3.
5.1.7 3.8.3.
5.2.3 3.8.3.
5.1.5 3.8.3.
5.1.6 3.8.3.
5.2.1 3.8.3.
5.2.2 3.8.3.
6.4.2 3.8.2.
6.4.4 3.8.2.
5.2.7 3.8.2.
3.6 3.8.3.
5.1.9 3.8.3.
3.8.2 = Open\Close Codes
SMDC-16 Program Manual
Description
Report Codes
Emergency Report
Enter Install. Prog
Exit Error
Exit Install. Prog.
Force Arm
Ground Fault
No Trip Code
O/C Buffer Full
O/C Buffer Over
On Premise Arm
Open Code (all)
Open Code (user)
Open Exception
Open Restore
Self Test
Special PIN
TLM Fault
TLM Restore
Unauthorized User
Zone Alarm
Zone Bypass
Zone Cancel
Zone Restore
Zone Trouble
/
3.8.3 = System Codes
28 of 59
Accepted Receivers
Varitech- Ademco SK FBI
Varitech- Ademco SK FBI
Varitech- Ademco SK FBI
Varitech- Ademco SK FBI
Varitech- Ademco SK FBI
Varitech- Ademco SK FBI
Varitech- Ademco SK FBI
Varitech- Ademco SK FBI
Varitech- Ademco SK FBI
Varitech- Ademco SK FBI
Varitech- Ademco SK FBI
Varitech
Check w/central station
Check w/central station
Menu Rcvr
Routing
4.5.2 3.8.3.
5.2.8 3.8.3.
5.2.5 3.8.2.
5.2.9 3.8.3.
5.3.7 3.8.2.
5.3.6 3.8.3.
2.8 3.8.3.
5.3.1 3.8.2.
5.3.2 3.8.2.
5.3.8 3.8.2.
6.4.1 3.8.2.
6.4.3 3.8.2.
5.2.6 3.8.2.
5.2.4 3.8.2.
1.3.4 3.8.3.
5.3.9 3.8.3.
3.7.1 3.8.3.
3.7.2 3.8.3.
5.3.3 3.8.3.
2.3.1 3.8.1
2.3.3 3.8.1
2.3.4 3.8.1
2.3.5 3.8.1
