Commissioning

5.4 Basic Programming

5.4.1 VLT ®
Programming
The low harmonic drive includes 2 LCPs: 1 to control the
frequency converter side and 1 to control the filter side.
Because of this unique design, the detailed parameter
information for the product is found in 2 places.
Detailed programming information for the frequency
5 5
converter portion can be found in the relevant
programming guide. Detailed programming information for
the filter can be found in the VLT
Operating Instructions.
The remaining sections in this chapter apply to the
frequency converter side. The active filter of the low
harmonic drives is pre-configured for optimal performance
and must only be turned on by pressing its [Hand On] key
after the frequency converter side is commissioned.

5.4.2 Commissioning with SmartStart

The SmartStart wizard enables fast configuration of basic
motor and application parameters.
•
SmartStart starts automatically at first power-up
or after initialisation of the frequency converter.
•
Follow the on-screen instructions to complete the
commissioning of the frequency converter.
Always reactivate SmartStart by selecting Quick
Menu Q4 - SmartStart.
•
For commissioning without use of the SmartStart
wizard, refer to chapter 5.4.3 Commissioning via
[Main Menu] or the programming guide.
NOTICE
Motor data is required for the SmartStart set-up. The
required data is normally available on the motor
nameplate.

5.4.3 Commissioning via [Main Menu]

Recommended parameter settings are intended for start-
up and check-out purposes. Application settings may vary.
Enter data with power ON, but before operating the
frequency converter.
1. Press [Main Menu] on the LCP.
2. Press the navigation keys to scroll to parameter
group 0-** Operation/Display and press [OK].
58
Low Harmonic Drive
®
Active Filter AAF 006
Danfoss A/S © 04/2015 All rights reserved.
®
VLT HVAC Drive FC 102 Low Harmonic Drive
1107 RPM
Main Menu
0 - ** Operation/Display
1 - ** Load/Motor
2 - ** Brakes
3 - ** Reference / Ramps
Illustration 5.2 Main Menu
3.
Illustration 5.3 Operation/Display
4.
Illustration 5.4 Basic Settings
5.
6.
7.
8.
9.
3.84 A
Press the navigation keys to scroll to parameter
group 0-0* Basic Settings and press [OK].
0.0% 0.00A
Operation / Display
0-0 * Basic Settings
0-1 * Set-up Operations
0-2 LCP Display
*
0-3 * LCP Custom Readout
Press the navigation keys to scroll to
parameter 0-03 Regional Settings and press [OK].
0.0% 0.00A
Basic Settings
0-03 Regional Settings
[0] International
Press the navigation keys to select [0] Interna-
tional or [1] North America as appropriate and
press [OK]. (This changes the default settings for
a number of basic parameters).
Press [Main Menu] on the LCP.
Press the navigation keys to scroll to
parameter 0-01 Language.
Select the language and press [OK].
If a jumper wire is in place between control
terminals 12 and 27, leave
parameter 5-12 Terminal 27 Digital Input at factory
default. Otherwise, select No Operation in
parameter 5-12 Terminal 27 Digital Input.
1 (1)
1(1)
0-
**
1(1)
0-0
*
