Mechanical Installation

3.3.4 Terminal Locations for Enclosure Size D1n/D2n

3 3
267.4
[10.5]
MAINS INPUT TERMINALS
Illustration 3.12 Terminal Locations, Enclosure Size D1n
30
®
VLT HVAC Drive FC 102 Low Harmonic Drive
784.6
[30.9]
29.0
[1.1]
476.0
[18.7]
88.0
266.2
[10.5] [3.5]
204.0
[8.0]
259.7
[10.2]
695.9
[27.4]
Danfoss A/S © 04/2015 All rights reserved.
78.3
[3.1]
39.2
[1.5]
1080.5
[42.5]
483.0
[19.0]
83.5
[3.3]
167.0
[6.6]
245.8
[9.7]
121.3
[4.8]
MOTOR
OUTPUT TERMINALS
MG16I302
