Introduction
I /I (R ) h<11
SC L SCE
<20 4%
20<50 7%
50<100 10%
100<1000 12%
>1000 15%
Table 1.11 Permissible Harmonic Currents at the PCC
®
The VLT HVAC Drive FC 102 Low Harmonic complies with the following standards:
•
IEC61000-2-4
•
IEC61000-3-4
•
IEEE 519
•
G5/4
MG16I302
Operating Instructions
11≤h<17 17≤h<23
2.0% 1.5%
3.5% 2.5%
4.5% 4.0%
5.5% 5.0%
7.0% 6.0%
Danfoss A/S © 04/2015 All rights reserved.
23≤h<35 35≤h
0.6% 0.3%
1.0% 0.5%
1.5% 0.7%
2.0% 1.0%
2.5% 1.4%
1 1
Total demand
distortion TDD
5%
8%
12%
15%
20%
