Module
Column valves
pH valve
Outlet valves
Versatile valve
UV monitors
Conductivity monitor
External air sensor
Fraction collectors
I/O-box
Sample pump
Core modules
Core modules need to be installed for the system to run.
Core module
System pump P9 A or P9H A
System pump P9 B or P9H B
Pressure monitor R9
ÄKTA pure Operating Instructions 29022997 AF
ÄKTA pure 25
V9-C
V9-Cs
V9-pH
V9-O
V9-Os
V9-V
U9-L
U9-M
C9
L9-1.5
L9-1.2
F9-C
F9-R
E9
S9
Description
A high precision pump, which delivers buffer or sample in purification
runs.
A high precision pump, which delivers buffer in purification runs.
Reads the system pressure after System pump A and System pump
B.
3 System description
3.1 ÄKTA pure instrument overview
Label in
ÄKTA pure 150
V9H-C
V9H-Cs
V9H-pH
V9H-O
V9H-Os
V9H-V
U9-L
U9-M
C9
L9-1.5
L9-1.2
F9-C
F9-R
E9
S9H
