Connect power to computer
equipment
Follow the manufacturer's instructions to connect power to the:
•
•
•
Connect to network
Follow the instructions below to make network connections.
Step
1
2
ÄKTA pure Operating Instructions 29022997 AF
computer
monitor
local printer, if used
Action
Connect a network cable between the Computer connector (network) on
the back of the instrument and the computer network card.
The illustration below shows the symbol of the network connector.
If the computer is to be connected to an external network, connect a network
cable between the main network card of the computer and a network wall
outlet.
Note:
If the computer has not been supplied by GE and if network configuration is
to be used, see Administration and Technical Manual for further information
on network settings.
4 Installation
4.2 Hardware installation
4.2.3 Connect system units
