Chapter 5. Programming considerations
This response is used in the inbound data stream in response to the Read All command.
22. Set Character Attribute Command/Response
ESC 4 Pa1 (outbound, inbound, or from the keyboard-Default Color mode)
ESC 4 Pa1 Pa2 Pa3 (outbound, Inbound, or from the keyboard-Program Color mode)
Parameter:
Pa1 Bit 7: 1 (Default Color mode) or 0 (Program Color mode)
6: 0 (Default Color mode) or 1 (Program Color mode)
5: Non-display (default is 0)
4: High Intensity (ignored in Program Color mode) (default is 0)
3: Blink (default is 0)
2: Underline (default is 0)
1: Reverse (default is 0)
Pa2 Bit 7: Always 0
6: Always 1
5: (Reserved)
4: (Reserved)
3: Foreground Color for Program Color mode
2:
1:
Pa3 Bit 7: Always 1
6: Always 0
5: (Reserved)
4: (Reserved)
3: Background Color for Program Color mode
2:
1 :
000 Black
001 Blue
o
1 0 Green (default)
o
1 1 Turquoise (Light Blue)
1 00 Red
1 0 1 Magenta (Purple)
1 1 0 Yellow
1 1 1 White
000 Black (default)
001 Blue
o
1 0 Green
o
1 1 Turquoise (Light Blue)
1 00 Red
1 0 1 Magenta (Purple)
1 1 0 Yellow
1 1 1 White
This command is used to specify the character attribute. Once the character attribute is specified,
it is effective until a new character attribute or a new field attribute appears in the data stream.
Parameters can be truncated in the middle of a parameter sequence by specifying a final parameter
value, The high intensity bit is meaningful only in the default color mode and not in the program
color mode.
This response is used in the inbound data stream in response to the Read All command. It is also
sent to the host when the host issues the Enable CA Transmission command. The high intensity
bit is meaningful only in the default color mode and not in the program color mode.
23. Enable CA Transmission Command
5-26
ESC
$ :
(outbound)
When this command is received, the display station sends the data stream including the Set
Character Attribute response in the inbound operation.
(
