21.4 VDI/VDE 3847 Mounting Blocks
Table 32: VDI/VDE 3847 Mounting Block (Aluminum)
Relay
No.
Gage Internal
Type
Gages
Material
Poppet
0
N/A
Poppet
2
Brass
Poppet
2
Brass
Poppet
2
Stainless
Poppet
2
Stainless
Spool
0
N/A
Spool
3
Brass
Spool
3
Brass
Spool
3
Stainless
Spool
3
Stainless
21.5
Mounting Kits
Table 33: Mounting Kits
Description
Shaft Converter - D to NAMUR
Direct Mount – 500MD+
(IEC 534 part 6 FlowTop, Kämmer KA, Kämmer
KP, and standard NAMUR linear valves)
82
Logix
520MD+ and 510+ Digital Positioners FCD LGENIM0105-15-AQ – 05/16
®
Pressure Units
Part-no.
N/A
307308.999.000
PSI (Bar/kPa)
307309.999.000
PSI (kg/cm2)
307310.999.000
PSI (Bar/kPa)
307311.999.000
PSI (kg/cm2)
307312.999.000
N/A
307313.999.000
PSI (Bar/kPa)
307314.999.000
PSI (kg/cm2)
307315.999.000
PSI (Bar/kPa)
307316.999.000
PSI (kg/cm2)
307317.999.000
Part-no.
314586.999.000
