Route the external cable through the electrical conduit ports in
the base and connect the external cable to the auxiliary card. See
Figure 42: Multi-Function Card.
9.
Replace the auxiliary card clips.
10. Reinstall the main cover.
Auxillary Card
Terminals
+
-
Figure 50: Auxiliary Card
60
Logix
520MD+ and 510+ Digital Positioners FCD LGENIM0105-15-AQ – 05/16
®
