7847i-E Installation and Setup Guide
CSIP 3
Service OK
Testing CSIP 2
Does Not Exist
CIP1
OK/Fail N/A

Possible Errors Running Network Diagnostics

Errors may occur at either while tracing the connection to a given receiver or while testing
the service at a given receiver. The following list highlights the most common errors. Please
contact the AlarmNet Technical Assistance Center (TAC) for help regarding any errors NOT
listed below.
Possible Errors
Testing CSIP x
FAIL before Gtwy
Testing CSIP x
FAIL at Gtwy
Testing CSIP x
FAIL on IP Addr
6-2
The service at the receiver on CS IP 3 is functioning. See below for
possible errors that may occur at this stage of testing.
If CS IP 2 and/or CS IP 3 are not programmed, display will read.
A summary of the tests is displayed after CS IP 3 is tested. The
CIP2 CIP3
example shows that CS IP 2 and/or CS IP 3 are not programmed.
N/A
While tracing the connection to CS IP x, the trace fails before ever
reaching the local gateway (router).
While tracing the connection to CS IP x, the trace fails after
reaching the local gateway (router).
While tracing the connection to CS IP x, the trace fails after
reaching the CS IP.
