IP Address
Subnet Mask
DMZ Host Type
Outgoing Interface
DMZ Host IP List
Apply
Reset

4.2.2 Load Balance Policy

Vigor3300V+ supports a load balancing function. It can assign traffic with protocol type, IP
address for specific host, a subnet of hosts, and port range to be allocated in WAN interface.
User can assign traffic category and force it to go to dedicate network interface based on the
following web page setup. VoIP and VPN traffic can also be assigned to specific WAN
ports.
In the Network group, click the Load Balance Policy option. You will get the following
page.
Vigor3300V+ Series User's Guide
Set the private IP address of WAN interface.
Set the subnet mask value of WAN interface.
Choose NAT Mode or Routing Mode as the DMZ host type.
This setting is available when Routing Mode selected as DMZ
host type.
When DMZ Host type is set as Routing Mode, please type
the IP address here to be chosen in IP Alias in
Advanced>>NAT>>DMZ Host.
Click Apply to go back to the WAN Interface Configuration
page. To apply all settings, click Apply on the WAN Interface
Configuration page and reboot your router.
Click this button to clear all the configurations for this page.
109
