Destination IP
Destination Mask
Destination Port
Group Name
Protocol
Direction
Fragments
Block or Pass
Vigor3300V+ Series User's Guide
the port number to be the value of the Start Port column.
Otherwise, the port number ranges from the Start Port to the
End Port including the Start Port and the End Port.
(!=) - If the End Port column is empty, the port number is not
equal to the value of the Start Port column. Otherwise, this
port number is not between the Start Port and the End Port
including the Start Port and End Port.
(>) - Specifies the port number is larger than or equal to the
Start Port.
(<) - Specifies the port number is less than or equal to the
Start Port.
Between - Specifies the port number is between the Start
Port and End Port.
It means the destination IP address for this filter rule. Placing
the symbol "!" before a particular IP address will prevent this
rule from being applied to that IP address. It is equal to the
logical NOT operator.
It means the subnet mask for the destination IP.
It means the port for the destination IP.
It means the filter group for the current rule.
It is the protocol(s) for this filter rule.
The direction of packet flow VPN In is for incoming packets.
VPN Out is for outgoing packets, and Any is for both
directions.
It is the response to fragmented packets. There are three
options as below.
Do not care - Specifies no fragment options.
Unfragment - Applies the rule to unfragment packets.
Fragmented - Applies the rule to fragmented packets.
The action to be taken when packets match the rule. There are
four options:
145
