Port Block; Ddns Setup - Draytek VIGOR3300V+ User Manual

Enable/Disable
Server IP Address
Destination Port
Shared Secret
Confirm Shared Secret
Interface
Click Apply to reboot the system and apply the settings.

4.3.4 Port Block

The Port Block function provides a user to set lots of proprietary port numbers. Packets will
be dropped if destination ports (both TCP and UCP) of packets with these assigned port
numbers are on WAN and LAN. The advantage of this feature is to filter some unnecessary
packets or attacking packets on Internet environment or LAN network. Vigor3300 Series
supports ten port numbers to be blocked.
Click Advanced >> Port Block. You will get the following page.
Index
Status
Port Number
Click Apply to finish this setting.

4.3.5 DDNS Setup

The Dynamic DNS function allows the router to update its online WAN IP address, which
assigned by ISP or other DHCP server to the specified Dynamic DNS server. Once the router
is online, you will be able to use the registered domain name to access the router or internal
virtual servers from the Internet. DDNS is more popular on dynamic IP users, who typically
receive dynamic, frequently-changing IP addresses from their service provider.
Click Disable to disable this function. Click Enable to
activate this function.
Assign an IP address of a Radius server.
Assign a destination port number used for Radius function.
Assign a code for authentication to server. The RADIUS
server and client share a secret which is used to authenticate
the messages sent between them. Both sides must be
configured to use the same shared secret.
Confirm the code assigned in Shared Secret field.
Select one specific WAN interface to be used.
The number of each entry.
User can Disable or Enable this port to be blocked.
Assign a port number to be blocked in system.
130
Vigor3300V+ Series User's Guide
