ITEM NO DESCRIPTION
1 CARRIAGE ASSEMBLY - Y AXIS DRIVE
2 HOUSING - X CARRIAGE
3 X-Z DRIVE MOTOR
4 DRIVE WHEEL - X AXIS
5 ROLLER GUIDE
6 PC BOARD - CONNECTOR - X CARRIAGE
7 TAPPING SCREW - #4 PLASTITE
8 NYLOCK NUT - 6mm
9 BRKT - FFC CABLE ASSY
10 SCREW, # 8 - 18 X 1/4
11 WASHER, .25ID X .38OD X .016 SS
X AXIS CARRIAGE ASSEMBLY
D-16
QTY PART NO
1 1125987
1 1125066
1 1124015
2 1123961
4 1125068
1 1125517
2 V802186
4 V802235
1 1125300
1 V800634
4 1127883
