Vendo VUE 30 User Manual page 130

GFV Cabinet, set Y home adjustment
WORK CONTENTS : Required tools to set Y home adjustment.
NOTE : (1) Spacers will be provided by the Tooling shop.
2 of each Spacer;
0.250 inch and
0.075 inch
Diagnostic Tools:
Diagnostic; Test Mode;
Sensor Status
Diagnostic; Test Mode; Sensor Status
display.
are monitoring the |Yo| (Y sensor) status.
1
0.
Press "4"
to access
In this adjustment procedure we
#2 Phillips screw
driver and a 5/16 open
end wrench.
Diagnostic; Test Mode; Sensor Status
display. In this adjustment procedure we
are monitoring the |Yo| (Y sensor) status.
Press "4"
to reset
Press "4"
to reset
