- Page 1 V21 Parts & Service Manual REV A – 10/2013 All V21 Identified Equipment P/N: 1230255 PROGRAMMING SECTION 12.4 PROGRAMMING HV3 / CHAMELEON 12.4 Programming HV3 / CHAMELEON | P1-1 V21 ...
- Page 2 V21 Parts & Service Manual REV A – 10/2013 All V21 Identified Equipment P/N: 1230255 VEC 12.4 PROGRAMMING OPERATIONS NOTE: Some units may contain a European font display, in which case the “°” symbol will be replaced by the “ß” symbol. Example: 72°F will be 72 ß F. The VEC 12.4 Controller uses a 4-button programming system: Programming Buttons: # 1 –...
- Page 3 V21 Parts & Service Manual REV A – 10/2013 All V21 Identified Equipment P/N: 1230255 Diagnostics: See inner door of vendor or Troubleshooting section for errors and how to clear them. Coin Payout: Coin Payout Mode allows the operator to ‘test’ for proper operation of the changer tubes. 1.
- Page 4 V21 Parts & Service Manual REV A – 10/2013 All V21 Identified Equipment P/N: 1230255 Test Mode Display: Allows you to verify that all of the characters on the display illuminate. 1. At “Test Mode” press Button 4. 2. Press Button 2 or 3 to scroll until display reads “Test Mode - Display.” 3.
- Page 5 V21 Parts & Service Manual REV A – 10/2013 All V21 Identified Equipment P/N: 1230255 Sales Data: This Mode allows you to retrieve historical information regarding the number of units sold by vendor. To clear the individual selection sales data, you must have the MIS Auto Reset in the “Configuration”...
- Page 6 V21 Parts & Service Manual REV A – 10/2013 All V21 Identified Equipment P/N: 1230255 Set Depth: This Mode allows you to set the depth of each column. In this mode, you have the option of setting the columns for single, double, triple or quadruple depths. 1.
- Page 7 V21 Parts & Service Manual REV A – 10/2013 All V21 Identified Equipment P/N: 1230255 and receive change without first attempting a vend. OFF - The consumer can insert a bill into the validator, press the coin return button and immediately receive change.
- Page 8 V21 Parts & Service Manual REV A – 10/2013 All V21 Identified Equipment P/N: 1230255 Space to Sales: Allows you to program which column will vend when you choose a desired selection button. There are 6 preset configurations (See inner door label for preset options). You also have the option of doing a custom space to sales.
- Page 9 V21 Parts & Service Manual REV A – 10/2013 All V21 Identified Equipment P/N: 1230255 To set the clock: 1. Press Button 4 at the “Set Clock” prompt. You will be able to scroll through the following options by pressing Button 2 or 3. ‐...
- Page 10 V21 Parts & Service Manual REV A – 10/2013 All V21 Identified Equipment P/N: 1230255 5. Press Button 4 to save changes. 6. Press Button 1 to exist and return “Refrigeration” on display. To display the temperature: 1. Press Button 4 when the display reads “Refrigeration.” 2.
- Page 11 V21 Parts & Service Manual REV A – 10/2013 All V21 Identified Equipment P/N: 1230255 Fan Mode 2 The refrigeration system shall have an fan mode of operation in which the evaporator fan will be turned on/off based on the number of vended product per unit hour . When the fan mode 2 is activated through the Service Modes the controller shall turn on/off the compressor and evaporator fans, based on the following method.
- Page 12 V21 Parts & Service Manual REV A – 10/2013 All V21 Identified Equipment P/N: 1230255 To program the “Discount” feature, you must enter the following information: Start Time - When the discounting begins Start Day Stop Time - When the discounting ends Stop Day Selections Amount –...
- Page 13 V21 Parts & Service Manual REV A – 10/2013 All V21 Identified Equipment P/N: 1230255 12.4 Programming HV3 / CHAMELEON | P1-13 V21 ...
- Page 14 V21 Parts & Service Manual REV A – 10/2013 All V21 Identified Equipment P/N: 1230255 12.4 Programming HV3 / CHAMELEON | P1-14 V21 ...
