ITEM NO DESCRIPTION
1 SERVICE DOOR ASSEMBLY
2 CONTROL PANEL
3 DOOR GUARD
4 DOOR ROLLER ASSEMBLY
5 T-HANDLE LOCK ASSEMBY (SEE D24)
6 KEYPAD ASSEMBLY (SEE D17)
7 COIN ENTRY & COIN RETURN ASSEMBLY (SEE D18-D19)
8 DBV PLUG
9 INSULATED GLASS PANEL
10 GLASS RETAINER - TOP & BOTTOM
11 GLASS RETAINER - RIGHT & LEFT
12 LATCH SLIDER BAR ASSEMBLY, T-HANDLE LOCK
LATCH SLIDER BAR ASSEMBLY, ELECTRONIC LOCK
13 GLIDE, NYLON
* NOTE: WHEN ORDERING SERVICE DOOR ASSEMBLY, CONTROL PANEL, OR DOOR GUARD,
PLEASE PROVIDE 9-CODE AND MANUFACTURER'S DATE CODE.

DOOR ASSEMBLY

D-3
QTY. PART NO
~ *
1 *
1 *
1 1120564-7
1 1127407
1 1127321
~ ~
1 388216
1 1125109
2 1126250
2 1126250-1
1 1125550
1 1125550-1
5 1126532
05/2006
