Vendo VUE 30 User Manual page 85

ITEM NO DESCRIPTION
1 Y RAIL ASSEMBLY, LATCH SIDE
2 EXTRUSION RAIL - Y AXIS - RIGHT
3 STRIP - DRIVE TRACK - Y AXIS
4 8-18 7/16 HEX SLOT STL-ZINC
5 BRKT - STOP - Y RAIL
6 SCREW, #10 - 16 X 3/8
7 WSHR .375 O.D. X .170 I.D.
8
DRIVE CARRAGE ASSY - Y AXIS - RIGHT
Option #1
DRIVE CARRAGE ASSY - Y AXIS - RIGHT
DRIVE WHEEL - Y AXIS
8
Option #2
SPACER,MAGNET,X-HOME
MAGNETIC ACTUATOR-HAMLIN
9 PAD, Y-AXIS STOP, GFV
Y RAIL ASSEMBLY - RIGHT / LATCH SIDE
D-12
QTY PART NO
1 1128144
2 1128139
1 1128142
2 V800586
1 1127860
2 V802212
4 V801455
1 1127862
1 1125080
1 1127330
1 1127891
1 1125941
1 1127935
05/2006
