RSC Condensing Unit Frame Assembly &
Kit #:1238795
Document Part #: 1238523
Revision: B
Subject:
INSTAL INSTRUC,RSC FRAME/REFRIG
Quantity
2
2
2
2
1
1
1
8
8
27
2
1
1
1
1
1238523A
Installation
Parts List
Part Number
1238019
Bracket, Anti-Tip
Bracket, Condenser, Angle
1238442
Bracket, Condenser, Vertical
1238027
Bracket, Condenser, U-Channel
1238434
Crossbrace, Upper, Condenser
1240013
Crossbrace, Lower, Condenser
1238817
Clamp, Condenser Tie-Down
1240005
Bolt, 3/8-16 x 1 Hex Head
V802291
Nut, 3/8-16, Nylok
V802062
V802141
Screw, 10-16 x ½ Hex Head
V802087
Screw, 8-15 x ½ Truss Head
1028847
Dryer C-053-S Sporlan
1028855
Sight Glass SA-13S Sporlan
1246895
Line set, Copper, RSC, 10 ft.
Instal Instruc,RSC Frame/Refrig
1238523
ECN: 56174
Date: 2-2-2016
Description
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vendo RSC
Summary of Contents for Vendo RSC
- Page 1 RSC Condensing Unit Frame Assembly & Installation Kit #:1238795 Document Part #: 1238523 ECN: 56174 Revision: B Date: 2-2-2016 Subject: INSTAL INSTRUC,RSC FRAME/REFRIG Parts List Quantity Part Number Description 1238019 Bracket, Anti-Tip Bracket, Condenser, Angle 1238442 Bracket, Condenser, Vertical 1238027...
- Page 2 Push tabs against the bottom of the RSC Side panel Install two V802141 screws --------------------------------------------------------------------------------------------------------------------------------------------- Step 3: Place frame on top of Attach RSC and push it up frame to against the side panel Install using 23 V802141 screws Side panel 1238523A...
- Page 3 Step 4: Place condensing Note: Condensing unit is heavy, two or more persons unit on frame should lift. Note: The top of the RSC is not designed to support the condensing unit without the frame. Condenser must be this side...
- Page 4 ----------------------------------------------------------------------------------------------------------------------------------------- Note: Steps 6 through 9 must be performed by a qualified refrigeration technician. Step 6: Using the provided line set, connect the outlet and inlet of the display case to the condensing unit as shown in the pictures. 1028855 1028847 Note: The line set should NOT be cut but coiled up to the right length.
- Page 5 Step 8: Connect the electrical box on the condensing unit to a power source as shown in the attached figure. The condensing unit is rated for 208/230V-1-60. VDPTCU005 = 21.6A MCA VDPTCU006 = 14.9A MCA ----------------------------------------------------------------------------------------------------------------------------------------- Step 9: a.) Confirm that the unit is free of leaks using pressurized nitrogen at approximately 150 psig and then pull a vacuum down to 200 microns for at least 30 minutes.
