ITEM NO DESCRIPTION
1 Y-RAIL ASSEMBLY, HINGE SIDE
2 EXTRUSION RAIL - Y AXIS - LEFT
3 STRIP - DRIVE TRACK - Y AXIS
4 BRKT - STOP - Y RAIL
5 8-18 7/16 HEX SLOT STL-ZINC
6 SCREW, #10 - 16 X 3/8
7 WSHR .375 O.D. X .170 I.D.
8
DRIVE CARRAGE ASSY - Y AXIS - LEFT
Option #1
DRIVE CARRAGE ASSY - Y AXIS - LEFT
8
Option #2 DRIVE WHEEL - Y AXIS
PAD, Y-AXIS STOP, GFV
Y RAIL ASSEMBLY - LEFT / HINGE SIDE
D-10
QTY. PART NO
1 1128143
1 1128139
1 1128142
1 1127860
2 V800586
2 V802212
4 V801455
1 1127863
1 1125079
1 1127330
1 1127935
05/2006
