Footrest

pos.
1 Upper screw fastening passenger
footrests to frame side panels
2 Lower TCEI screw fastening passen-
ger footrests to rider footrest mount-
3 TCEI screw fastening rider footrest
mounting to frame
4 Footrest rubber fastener narrow nut
5 TCEI screw fastening rider footrest

RIGHT FOOTREST

•
Unscrew and remove the upper screw
(1).
•
Unscrew and remove the two outer
screws (2).
email: info@motomatrix.co.uk
Description
ing
mounting
F
OOTRESTS
Type Quantity
M8x35 2 25 Nm (18.44 lbf ft)
M8x35 2 25 Nm (18.44 lbf ft)
M8x35 4 30 Nm (22.12 lbf ft)
M5 4 6 Nm (4.42 lbf ft)
M6x16 6 10 Nm (7.37 lbf ft)
Bodywork
Torque Notes
Loct. 243
Loct. 243
Loct. 243
-
-
BODYW - 387
