APRILIA DORSODURO 1200 ABS - ATC Service Station Manual page 115

Manuals by Motomatrix / www.motomatrix.co.uk / The Solution For Lost Motorcycle Coded Keys.
DORSODURO 1200 ABS - ATC
5. HIGH - LOW BEAM BULB
6. TAIL LIGHT BULB
7. HIGH BEAM LIGHT RELAY
8. LIGHT LOGIC RELAY
9. HORN
10.Left light switch
11.INSTRUMENT PANEL DIAGNOSIS
12.INSTRUMENT PANEL
13.FRONT STOP SWITCH
14.REAR STOP SWITCH
15.CLUTCH SWITCH
16.IGNITION SWITCH
17.MAIN INJECTION RELAY
18.IMMOBILIZER AERIAL
19.REAR LEFT TURN INDICATOR
20.Rear right turn indicator
21.LICENSE PLATE LIGHT BULB
22.TAILLIGHT ASSEMBLY
23.RECOVERY LOGIC RELAY
24.Secondary fuses
25.ABS CONTROL UNIT
26.FRONT ABS SENSOR
27.REAR ABS SENSOR
28.Voltage regulator
29.ALTERNATOR
30.STARTER MOTOR
31.START-UP RELAY
32.ABS CONTROL UNIT FUSE
33.MAIN FUSE
34.BATTERY
35.AUXILIARY INJECTION RELAY
36.OIL PRESSURE SENSOR
37.FAN
38.FAN CONTROL RELAY
39.Right light switch
40.-
41.FUEL RESERVE SENSOR (PIC)
42.FUEL PUMP
email: info@motomatrix.co.uk
Electrical system
ELE SYS - 115
