Bodywork
pos. Description
1 TEFL screw fastening fuel pump
2 TEFL screw fastening fuel pipe
•
Remove both side fairings.
•
Remove the rubber ring on the ignition
switch assembly.
•
Unscrew and remove the screw.
•
Remove the cover of the ignition switch assembly.
See also
Side body panels
•
Unscrew and remove the two front
screws retaining the fuel tank, collect-
ing the corresponding bushings.
BODYW - 394
email: info@motomatrix.co.uk
DORSODURO 1200 ABS - ATC
F
UEL PUMP
Type Quantity
M5x16 6 3 Nm (2.21 lbf ft)
M6x16 1 10 Nm (7.37 lbf ft)
Torque Notes
Loctite 518
-
