SPECIFICATIONS

D General
• Frequency coverage:
EUR Receive
118 ~ 174 MHz (Guaranteed only 144 ~ 146 MHz)
230 ~ 550 MHz (Guaranteed only 430 ~ 440 MHz)
Transmit
144 ~ 146 MHz, 430 ~ 440 MHz
ITR Receive
118 ~ 136.99166 MHz (Not guaranteed),
144 ~ 146 MHz, 430 ~ 434 MHz, 435 ~ 438 MHz
Transmit
144 ~ 146 MHz, 430 ~ 434 MHz,
435 ~ 438 MHz
USA Receive
118 ~ 174 MHz (Guaranteed only 144 ~ 148 MHz)
230 ~ 550 MHz (Guaranteed only 430 ~ 450 MHz)
Transmit
144 ~ 148 MHz, 430 ~ 450 MHz
EXP Receive
118 ~ 174 MHz (Guaranteed only 144 ~ 148 MHz)
230 ~ 550 MHz (Guaranteed only 430 ~ 440 MHz)
Transmit
137 ~ 174 MHz (Guaranteed only 144 ~ 148 MHz)
400 ~ 470 MHz (Guaranteed only 430 ~ 440 MHz)
• Mode:
• No. of memory channels:
• No. of program scan channels:
• No. of call channels:
57
BASIC MANUAL
F2D/F3E (FM/FM-N), F7W (DV),
A3E (AM/AM-N) RX only
1000 channels
50 channels
( 2 channels × 25 pairs)
4 channels
(2 channels × 2 bands)
• No. of repeater lists:
• No. of GPS memory:
• Antenna impedance:
• Usable temperature range:
• Frequency stability:
• Digital transmission speed:
• Voice coding speed:
• Frequency resolution:
• Power supply:
• Current drain:
Transmit
Maximum current drain:
Receive
Standby:
Maximum audio:
• Dimensions:
• Weight (approximate):
1500
300
50 Ω (SO-239)
–10˚C to +60˚C
(+14˚F to +140˚F)
±2.5 ppm (–10˚C to +60˚C, +14˚F
to +140˚F) at +25˚C (+77˚F)
4.8 kbps
2.4 kbps
5 kHz, 6.25 kHz, 8.33 kHz*,
10 kHz, 12.5 kHz, 15 kHz,
20 kHz, 25 kHz, 30 kHz, and
50 kHz
* Selectable depending on the
operating band or mode.
13.8 V DC ±15%
(negative ground)
≤ 13.0 A (at High)
≤ 7.5 A (at Mid)
≤ 5.0 A (at Low)
≤ 0.9 A
≤ 1.2 A
150(W) × 40(H) × 171.9(D) mm
5.9(W) × 1.6(H) × 6.8(D) inch
(projections are not included)
1.2 kg, 2.6 lb
( microphone, cable, and bracket
are not included)
