Component Specifications

BIN THERMOSTAT

Model
RF Models
RF0244 / RF0266
RF0385 / RF0388
RF0399 / RF1200
RF2300
RFS Models
RFS0244
RF0644 / RFS1200
RN Models
RNS0308 / RNS0385
RF Models
RF0300 / RF0600
RFS Models
RFS0300 / RFS0650

LOW TEMPERATURE THERMOSTAT

Evaporator safety thermostat)

Model
RF Models
RF0244 / RF0266
RF1200 / RF2300
RFS Models
RFS0244 / RFS1200
RFS2300
RF Models
RF0300 / RF0388
RF0385 / RF0399
RF0644 / RF650
RFS Models
RFS0300
RNS Models
RNS0385
Part Number 000007661 11/16
Setting
5
4
Setting Cut-Out
5 -9°F ±1
-23°C ±.1
7 -11°F ±.1
-24°C ±.1
Cut-Out
37°F ±1
3°C ±.1
36°F ±1
2.2°C ±.1
Cut-In
10°F ±1
-12°C ±.1
7 °F±.1
-14°C ±.1
Cut-In
43°F ±1
6°C ±.1
42°F ±1
5.6°C ±.1
