Rns0308 - Manitowoc RNS0244 Technician's Handbook

Flake & nugget ice machine r series
Hide thumbs
Table of Contents

Advertisement

RNS0308

4
3
TUBING DIAGRAM LEGEND
1
2
3
4
5
6
Part Number 000007661 11/16
5
1
Compressor
Condenser (air or water cooled)
Liquid Line Drier
Heat Exchanger
Automatic Expansion Valve
Evaporator
6
2
277
