Page 1 RF/RFS & RN/RNS Models Flake & Nugget Ice Machine Technician’s Handbook Part Number 000007661 Rev02 02/20...
Page 3: Safety Notices
Safety Notices As you work on Welbilt equipment, be sure to pay close attention to the safety notices in this handbook. Disregarding the notices may lead to serious injury and/ or damage to the equipment. Throughout this handbook, you will see the following types of safety notices: Warning Text in a Warning box alerts you to a potential...
Page 4: Procedural Notices
Procedural Notices As you work on Welbilt equipment, be sure to read the procedural notices in this handbook. These notices supply helpful information which may assist you as you work. Throughout this handbook, you will see the following types of procedural notices: Important Text in an Important box provides you with information that may help you perform a procedure...
Page 5: Read These Before Proceeding
Caution Proper installation, care and maintenance are essential for maximum performance and trouble- free operation of your Manitowoc equipment. If you encounter problems not covered by this manual, do not proceed, contact Welbilt. We will be happy to provide assistance.
Page 6 Warning Do not use electrical appliances or accessories other than those supplied by Welbilt for your ice machine model. Warning Two or more people or a lifting device are required to lift this appliance. Warning This equipment contains high voltage electricity and refrigerant charge.
Page 7 Warning Do not operate equipment that has been misused, abused, neglected, damaged, or altered/modified from that of original manufactured specifications. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision concerning use of the appliance by a person responsible for their safety.
Page 8 Warning It is the responsibility of the equipment owner to perform a Personal Protective Equipment Hazard Assessment to ensure adequate protection during maintenance procedures. Warning Two or more people are required to move this equipment to prevent tipping.
Page 9 Warning When using electric appliances, basic precautions must always be followed, including the following: Read all the instructions before using the appliance. To reduce the risk of injury, close supervision is necessary when an appliance is used near children. Do not contact moving parts. Only use attachments recommended or sold by the manufacturer.
Page 10 THIS PAGE INTENTIONALLY LEFT BLANK...
Page 11: Table Of Contents
Model/Serial Number . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 Manitowoc Cleaner and Sanitizer . . . . . . . . . . . . . . 19 Ice Machine Warranty Information .
Page 12 Sequence of Operation Ice Making Sequence of Operation . . . . . . . . . . . . . 43 RF0244/RNS0244/RF0266/RF0385/RFS0385/ RNS0385/RF0388/RF0399 . . . . . . . . . . . . . . . . . . . . . 43 RF0300 .
Page 13 RF2300R/RFS2300R Troubleshooting . . . . . . . . . 118 Head Section For Rack Refrigeration systems . 118 Rotation Sensor Operation . . . . . . . . . . . . . . . . . . . 118 RN0400 Troubleshooting .
Page 14 RF1200W . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 186 RF1278C With RCU1075 .
Page 15 Diagrams Wiring Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 221 Flake Models .
Page 16 Refrigeration Tubing Schematics . . . . . . . . . . . . . . 268 Flake Models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 268 RF0244/RFS0244/RF0266/RF0300/RF0385/ RF0388/RF0399/RF0644/RF0650 .
Page 17: General Information
General Information Model Numbers SELF CONTAINED AIR & WATER-COOLED MODELS Flake Models Self Storage Self Storage Modular Air- Modular Air-Cooled Water- Cooled Water- Cooled Cooled RF0244A – – – RF0266A – – – RF0385A – – – RF0388A – – –...
Page 18: Nugget Models
NUGGET MODELS Self Storage Self Storage Modular Air- Modular Air-Cooled Water- Cooled Water- Cooled Cooled RNS0244A – – – – RNS0308A – RNS0385A – – – RN0408A – – – – – RNS1008A – – – RN1008A RN1009W – – RN1408A RN1409W QUIETQUBE MODELS WITH REMOTE CONDENSING...
Page 19: Rack Units
RCU condensing units. Model/Serial Number These numbers are required when requesting information from your local Manitowoc Distributor, or Manitowoc Ice. The model and serial number are listed on the MODEL/SERIAL NUMBER DECAL affixed to the ice machine. Manitowoc Cleaner and Sanitizer Manitowoc Ice Machine Cleaner and Sanitizer are available in 16 oz.
Page 20: Ice Machine Heat Of Rejection
Ice Machine Heat of Rejection Series Ice Heat of Rejection Machine Air Conditioning* Peak RF Flake Models RF0244A 2400 5000 RF0266A 2400 5000 RF0300A 2400 2400 RF0385A 3500 5200 RF0388A 3500 5200 RF0399A 3500 5200 RF0644A 7700 10250 RF0650A 5200 7700 RF0650W 5200...
Page 21 Ice Machine Heat of Rejection Series Ice Heat of Rejection Machine Air Conditioning* Peak RN Nugget Models RN0408A 3800 5400 RN1008A 11300 12800 RN1009W 11300 12800 RN1078C 11300 12800 RN1278C 7500 14000 16000 RN1408A 16400 RN1409W 16000 16400 RNS Nugget Models RNS0244A 2400 5000...
Page 22 THIS PAGE INTENTIONALLY LEFT BLANK Part Number 000007661 Rev02 02/20...
Page 23: Installation
Installation Installation Requirements The location selected for the ice machine must meet the following criteria. If any of these criteria are not met, select another location. • Air temperature: • RF or RFS Flake Models - Minimum 50°F (10°C), Maximum 110°F (43°C) •...
Page 24: Potable Water Requirements
If water pressure exceeds maximum pressure (70 psig [483 kPa] RN1000; 80 psig [552 kPa] for all other models) obtain a water pressure regulator from your Manitowoc distributor. • A water shut-off valve is required to clean the ice machine.
Page 25: Ice Machine Clearance Requirements
Ice Machine Clearance Requirements Head Self- Self- QuietQube Sections Contained Contained Air-Cooled Air-Cooled Water- Cooled* Back 5” (12.7 cm) 5” (12.7 cm) 5” (12.7 cm) Sides/Top 8” (20.3 cm) 8” (20.3 cm) 8” (20.3 cm) RCU Units Remote Condensing Unit* Front/Back 24”...
Page 26: Cooling Tower Applications
Cooling Tower Applications A water cooling tower installation does not require modification of the ice machine. The water regulator valve for the condenser continues to control the refrigeration discharge pressure. It is necessary to know the amount of heat rejection, and pressure drop through the condenser and water valves (inlet and outlet) when using a cooling tower on an ice machine.
Page 27: Electrical Service
Electrical Service Warning All wiring must conform to local, state and national codes. VOLTAGE The maximum allowable voltage variation is ± 10% of the rated voltage on the ice machine model/serial number plate at compressor start-up. FUSE/CIRCUIT BREAKER A separate fuse/circuit breaker must be provided for each ice machine.
Page 28: Maximum Breaker/Minimum Circuit Amperage
MAXIMUM BREAKER/MINIMUM CIRCUIT AMPERAGE CHART Model Minimum Circuit Maximum Fuse Ampacity Size RNS1008A-261 14.2 RNS1009W-261 13.7 RNS1008AZ-251 11.7 RNS1009WZ-251 11.2 RNS0608A-261 RNS0608A-161 16.3 RNS0609W-261 RNS0609W-161 15.4 RNS0608AZ-251 RNS0609WZ-251 RNS1078C-261 RNS1078C-161 Due to continuous improvements, this information is for reference only. Please refer to the ice machine serial number tag to verify electrical data.
Page 29: Maintenance
Maintenance procedures covered in this manual are not covered by the warranty. Caution Use only Manitowoc approved Ice Machine Cleaner (part number 000000084) and Sanitizer (part number 9405653). Do not mix Cleaner and Sanitizer solutions together. It is a violation of Federal law to use these solutions in a manner inconsistent with their labeling.
Page 30 Procedure to Clean/Sanitize Use Ice Machine Cleaner part number 000000084. Use Ice Machine Sanitizer part number 9405653. Step 1 Remove front and top covers and set the toggle switch to the OFF position. Step 2 Remove all ice from the bin. Step 3 Turn off the ice making water supply and drain water from evaporator and reservoir.
Page 31 Step 7 Move the toggle switch to the ON position. The ice machine will make ice with the cleaning solution and deposit the ice in the bin. Add the remaining cleaner/ water solution as the water level in the reservoir drops. NOTE: Do not allow the cleaner/water level to drop below the minimum water level.
Page 32: Heavily Scaled Cleaning Procedure
Step 13 Refer to chart and premix water and sanitizer. Amount of Water Amount of Sanitizer 1 Gallons (4 L) Water 1/2 ounce (15 ml) Step 14 Fill the evaporator and reservoir with sanitizer/ water solution. Step 15 Move the toggle switch to the ON position. The ice machine will make ice with the sanitizer/water solution and deposit the ice in the bin.
Page 33 Step 3 Turn off the ice making water supply. Step 4 Remove the top cover from water reservoir. Step 5 Refer to chart and premix cleaner with lukewarm water in a non-metallic container. Model Water Mix Cleaner and Water Reservoir Use Ice machine nickel Capacity safe cleaner, part number...
Page 34: Parts Removal For Cleaning/Sanitizing
PARTS REMOVAL FOR CLEANING/SANITIZING Warning Disconnect electric power to the ice machine at the electric switch box and wear rubber gloves and safety goggles (or face shield) while handling cleaner or sanitizer. NOTE: Do not mix Cleaner and Sanitizer solutions together.
Page 35: Ice Chute Removal - Rfs & Rns Models
ICE CHUTE REMOVAL - RFS & RNS MODELS RFS0300/RNS0308/RFS1200/RFS2300 NOTE: A limited number of RF models have this type of ice chute also. 1. Place the toggle switch in the OFF position, turn off the water supply and disconnect electrical power to the ice machine.
Page 36: Ice Chute Removal - Rf Models
ICE CHUTE REMOVAL - RF MODELS RF0300/RF0650/RF1200/RF2300 NOTE: A limited number of these models have the ice chute listed on the previous page. 1. Place the toggle switch in the OFF position, turn off the water supply and disconnect electrical power to the ice machine.
Page 37: Ice Chute Switch Actuator Removal
TIP TOP OF ICE LOOSEN SUPPORT CHUTE BACK AND BOLTS LIFT TO REMOVE ICE CHUTE SWITCH ACTUATOR REMOVAL RFS0300/RF0650/RF1200/RFS1200/RF2300/RFS2300 1. Pull to remove nylon end cap. 2. Slide pin to remove. 3. Remove both sections of the pressure switch bracket. INCORRECT REASSEMBLY CAN RESULT IN AN ICE MACHINE THAT WILL NOT RUN...
Page 38: Cleaning Sanitizing Procedure Rn0400
CLEANING SANITIZING PROCEDURE RN0400 Use Ice Machine Cleaner part number 000000084. Use Ice Machine Sanitizer part number 94-0565-3. Step 1 Disconnect power, remove front, top and right panels and set the compressor rocker switch to the OFF position. Step 2 Remove all ice from the bin/dispenser.
Page 39 Step 8 Disconnect power, then drain the water from the evaporator and reservoir through the evaporator/ reservoir drain line - Using a pitcher, fill and drain the evaporator/reservoir 4 times and reinsert the hose into the hose clip. Step 9 Refer to chart and premix water and sanitizer.
Page 40 Step 16 Turn on the ice making water supply, reconnect power and move the compressor rocker switch to ON. Step 17 Allow the ice machine to run for 10 minutes, then place the compressor rocker switch in the OFF position, disconnect power and discard all ice produced. Warning To prevent injury disconnect main supply power to the dispenser (when used) before cleaning or...
Page 41: Cleaning The Air Filter And Condenser
CLEANING THE AIR FILTER AND CONDENSER Warning Disconnect electric power to the ice machine at the electric service switch before cleaning the condenser. The condenser fins are sharp. Use care when cleaning them. Air-Cooled Condenser Clean the condenser at least every six months. Follow the steps below.
Page 42: Removal From Service/Winterization
Removal from Service/Winterization Caution If water is allowed to remain in the ice machine in freezing temperatures, severe damage to some components could result. Damage of this nature is not covered by the warranty. Follow the procedure below. 1. Disconnect the electric power at the circuit breaker or the electric service switch.
Page 43: Sequence Of Operation
Sequence of Operation Ice Making Sequence of Operation NOTE: Flake ice machines use an auger to remove ice from the evaporator. Occasional noises (creaks, groans, squeaks, or pops) are a normal part of the ice making process. RF0244/RNS0244/RF0266/RF0385/RFS0385/ RNS0385/RF0388/RF0399 Self-Contained Air-Cooled When the toggle switch is placed in the “ON”...
Page 44: Rf0300
RF0300 Self-Contained Air-Cooled When the toggle switch is placed in the “ON” position the following controls must be in the closed position before the ice machine will start: Bin Thermostat Ice Chute Safety Switch Low Water Level Switch Low Evaporator Temperature Thermostat Placing the toggle switch in the ON position starts the gear motor and a 10 minute compressor time delay.
Page 45: Rfs0300/Rns0308
RFS0300/RNS0308 Self-Contained Air-Cooled When the toggle switch is placed in the “ON” position the following controls must be in the closed position before the ice machine will start: Bin Thermostat Ice Chute Safety Switch Low Water Level Switch High Pressure Cut-out Switch Low Pressure Cut-Out Switch Placing the toggle switch in the ON position starts the gear motor and a compressor time delay¹.
Page 46: Rf0644/Rf0650/Rf1200/Rfs1200/Rf2300
RF0644/RF0650/RF1200/RFS1200/RF2300/RFS2300 Self-Contained Air-Cooled When the toggle switch is placed in the ON position the following controls must be in the closed position before the ice machine will start: Bin Thermostat High Pressure Cut-out Switch Ice Chute Safety Switch Low Pressure Switch Low Water Level Switch Placing the toggle switch in the ON position starts the gear motor.
Page 47: Rf1200C/Rf2300C
RF1200C/RF2300C QuietQube Remote Air-cooled Models with Remote Condensing Unit When the toggle switch is placed in the ON position the following controls must be in the closed position before the ice machine will start: Bin Thermostat High Pressure Cut-out Switch Ice Chute Safety Switch Low Pressure Switch Low Water Level Switch...
Page 48 RF1200C/RF2300C Head Section with Rack Refrigeration system When the toggle switch is placed in the ON position the following controls must be in the closed position before the ice machine will start: Bin Thermostat Ice Chute Safety Switch Low Water Level Switch Placing the toggle switch in the ON position starts the gear motor.
Page 49: Rn0400
RN0400 Self-Contained Air-Cooled & Water-Cooled NOTE: Ice machines use an auger to remove ice from the evaporator. Occasional noises (creaks, groans, squeaks, or pops) are a normal part of the ice making process. Operation The ice machine will not start until: The compressor rocker switch is moved to “ON”.
Page 50 Step 1 Initial Startup With power supplied to the control board the PWR (power) light is energized. The bin thermostat closes (BE light on) and the water level probe checks for water. Part Number 000007661 Rev02 02/20...
Page 51 Step 2 Gear Motor & Compressor Startup The WTR light energizes and the gear motor, compressor and fan motor start. Two additional lights energize DR (drive) and C (compressor). Part Number 000007661 Rev02 02/20...
Page 52 Step 3 When the current to the compressor and gear motor drops, the current relays open. The PWR, DR, C, WTR and BE lights remain energized throughout the freeze cycle. Part Number 000007661 Rev02 02/20...
Page 53 Step 4 The bin/dispenser fills and the bin thermostat opens. The BE light de-energizes and 10 seconds later the BT light energizes and the C light de-energizes. The compressor and fan motor stop, although the gear motor will run for an additional 60 seconds. Part Number 000007661 Rev02 02/20...
Page 54 Step 5 The BT light is energized for 20 minutes to indicate the machine is in the 20 minute time delay period. Pressing the control board reset button cancels the time delay. Part Number 000007661 Rev02 02/20...
Page 55 Step 6 After 20 minutes the BT light de-energizes. The PWR and WTR lights remain energized. When the bin thermostat closes the ice machine starts at step 1. Part Number 000007661 Rev02 02/20...
Page 56 Part Number 000007661 Rev02 02/20...
Page 57: Rn1000/Rn1400
RN1000/RN1400 Self-Contained Air-Cooled & Water-Cooled NOTE: Ice machines use an auger to remove ice from the evaporator. Occasional noises (creaks, groans, squeaks, or pops) are a normal part of the ice making process. Operation The ice machine will not start until: The rocker switch is moved to ON.
Page 58 RN1000/RN1400 Indicator lights INDICATOR LIGHT LEGEND ON or OFF FLASHING • With line voltage supplied the green Power light is on and the CPU light flashing a heartbeat indicates the central processing unit is working. • Yellow lights indicate normal off conditions. •...
Page 59 Step 2 Time delay cycle normal light operation The bin fills with ice, the Low Bin light de-energizes and the Time delay light energizes. The compressor and gear motor immediately turn off and the condenser fan continues to run for 10 minutes before turning off. When the time delay ends and the Low bin light energizes the ice machine will restart.
Page 60: Rn1000C/Rn1200C
RN1000C/RN1200C QuietQube Remote Air-cooled Model with Remote Condensing Unit NOTE: Ice machines use an auger to remove ice from the evaporator. Occasional noises (creaks, groans, squeaks, or pops) are a normal part of the ice making process. Operation The ice machine will not start until: The rocker switch is moved to ON.
Page 61 RN1000/RN1400 Indicator lights INDICATOR LIGHT LEGEND ON or OFF FLASHING • With line voltage supplied the green Power light is on and the CPU light flashing a heartbeat indicates the central processing unit is working. • Yellow lights indicate normal off conditions. •...
Page 62 Step 2 Time delay cycle normal light operation The bin fills with ice, the Low Bin light de-energizes and the Time delay light energizes. The compressor and gear motor immediately turn off and the condenser fan continues to run for 10 minutes before turning off. When the time delay ends and the Low bin light energizes the ice machine will restart.
Page 63: Ice Production/Quality Check
Ice Production/Quality Check QUALITY CHECK Ice quality varies with ambient and water temperatures, and is measured by the amount of water in the ice. Generally speaking, higher incoming water temperature results in lower ice quality. Lower water temperature results in higher ice quality. ICE PRODUCTION CHECK NOTE: Ice production checks that are within 10% of the charted capacity are considered normal due to variances...
Page 64: Thermostat Settings
Thermostat Settings Bin Thermostat: The bin thermostat sensing bulb is located in the ice chute on modular models and in the bin thermostat holder on the right side of the bin on self storage models. The bin thermostat turns the ice machine on and off as the level of ice in the bin changes.
Page 65: Thermostat Setting Chart
Thermostat Setting Chart NOTE: Settings are for reference only. Factory setting is indicated on control label and overrides information listed on this page. Model Bin Thermostat Evaporator Setting Thermostat Setting RF0244 RFS0244 RNS0244 RF0266 RF0300 RFS0300 RNS0308 RF0385 RNS0385 RF0388 RF0399 RF0644 RF0650...
Page 66: Troubleshooting
Troubleshooting Diagnostic troubleshooting for the ice machine involves following flowcharts that are dependent on symptoms of the failed machine. Follow the flowcharts for the failure symptom and model you are working on. NOTE: Refer to the sequence of operation to determine where in the sequence the ice machine has failed.
Page 67 Part Number 000007661 Rev02 02/20...
Page 68 Part Number 000007661 Rev02 02/20...
Page 69 Part Number 000007661 Rev02 02/20...
Page 70 Part Number 000007661 Rev02 02/20...
Page 71 Part Number 000007661 Rev02 02/20...
Page 72: Rf0300 Troubleshooting
RF0300 Troubleshooting SELF-CONTAINED AIR-COOLED Normal Operation When the toggle switch is placed in the “ON” position the following controls must be in the closed position before the ice machine will start: Bin Thermostat Low Evaporator Temperature Thermostat Ice Chute Safety Switch Low Water Level Switch Placing the toggle switch in the ON position starts the gear motor and a 10 minute compressor time...
Page 73 Part Number 000007661 Rev02 02/20...
Page 74 Part Number 000007661 Rev02 02/20...
Page 75 Part Number 000007661 Rev02 02/20...
Page 76 Part Number 000007661 Rev02 02/20...
Page 77 Part Number 000007661 Rev02 02/20...
Page 78: Rfs0300/Rns0300 Troubleshooting
RFS0300/RNS0300 Troubleshooting SELF-CONTAINED AIR-COOLED When the toggle switch is placed in the “ON” position the following controls must be in the closed position before the ice machine will start: Bin Thermostat Ice Chute Safety Switch Low Water Level Switch High Pressure Cut-out Switch Low Pressure Cut-Out Switch Placing the toggle switch in the ON position starts the gear motor and a 10 minute compressor time delay.
Page 79 Part Number 000007661 Rev02 02/20...
Page 80 Part Number 000007661 Rev02 02/20...
Page 81 Part Number 000007661 Rev02 02/20...
Page 82 Part Number 000007661 Rev02 02/20...
Page 83 Part Number 000007661 Rev02 02/20...
Page 84: Rf0644/Rf0650/Rns0600/Rns1000/Rf1200
RF0644/RF0650/RNS0600/RNS1000/RF1200 RFS1200 Troubleshooting SELF-CONTAINED AIR-COOLED Normal Operation When the toggle switch is placed in the ON position the following controls must be in the closed position before the ice machine will start: Bin Thermostat High Pressure Cut-out Switch Ice Chute Safety Switch Low Pressure Switch Low Water Level Switch NOTE: Placing the toggle switch in the ON position starts...
Page 85 Part Number 000007661 Rev02 02/20...
Page 86 Part Number 000007661 Rev02 02/20...
Page 87 Part Number 000007661 Rev02 02/20...
Page 88 Part Number 000007661 Rev02 02/20...
Page 89 Part Number 000007661 Rev02 02/20...
Page 90: Rns1000/Rf1200C/Rfs1200C Troubleshooting
RNS1000/RF1200C/RFS1200C Troubleshooting QUIETQUBE REMOTE AIR-COOLED MODELS WITH REMOTE CONDENSING UNIT Normal Operation When the toggle switch is placed in the ON position the following controls must be in the closed position before the ice machine will start: Bin Thermostat High Pressure Cut-out Switch Ice Chute Safety Switch Low Pressure Switch Low Water Level Switch...
Page 91 Part Number 000007661 Rev02 02/20...
Page 92 Part Number 000007661 Rev02 02/20...
Page 93 Part Number 000007661 Rev02 02/20...
Page 94 Part Number 000007661 Rev02 02/20...
Page 95 Part Number 000007661 Rev02 02/20...
Page 96 Part Number 000007661 Rev02 02/20...
Page 97: Rf1200R/Rfs1200R Troubleshooting
RF1200R/RFS1200R Troubleshooting HEAD SECTION FOR RACK REFRIGERATION SYSTEMS Normal Operation When the toggle switch is placed in the ON position the following controls must be in the closed position before the ice machine will start: Bin Thermostat Ice Chute Safety Switch Low Water Level Switch Placing the toggle switch in the ON position starts the gear motor.
Page 98 Part Number 000007661 Rev02 02/20...
Page 99 Part Number 000007661 Rev02 02/20...
Page 100 Part Number 000007661 Rev02 02/20...
Page 101 Part Number 000007661 Rev02 02/20...
Page 102 Part Number 000007661 Rev02 02/20...
Page 103 Part Number 000007661 Rev02 02/20...
Page 104: Rf2300/Rfs2300 Troubleshooting
RF2300/RFS2300 Troubleshooting SELF-CONTAINED AIR-COOLED Normal Operation When the toggle switch is placed in the ON position the following controls must be in the closed position before the ice machine will start: Bin Thermostat High Pressure Cut-out Switch Ice Chute Safety Switch Low Pressure Switch Low Water Level Switch Placing the toggle switch in the ON position starts the...
Page 105 Part Number 000007661 Rev02 02/20...
Page 106 Part Number 000007661 Rev02 02/20...
Page 107 Part Number 000007661 Rev02 02/20...
Page 108 Part Number 000007661 Rev02 02/20...
Page 109 Part Number 000007661 Rev02 02/20...
Page 110 Part Number 000007661 Rev02 02/20...
Page 111: Rf2300C/Rfs2300C Troubleshooting
RF2300C/RFS2300C Troubleshooting QUIETQUBE REMOTE AIR-COOLED MODELS WITH REMOTE CONDENSING UNIT Normal Operation When the toggle switch is placed in the ON position the following controls must be in the closed position before the ice machine will start: Bin Thermostat High Pressure Cut-out Switch Ice Chute Safety Switch Low Pressure Switch Low Water Level Switch...
Page 112 Part Number 000007661 Rev02 02/20...
Page 113 Part Number 000007661 Rev02 02/20...
Page 114 Part Number 000007661 Rev02 02/20...
Page 115 Part Number 000007661 Rev02 02/20...
Page 116 Part Number 000007661 Rev02 02/20...
Page 117 Part Number 000007661 Rev02 02/20...
Page 118 Part Number 000007661 Rev02 02/20...
Page 119: Rf2300R/Rfs2300R Troubleshooting
RF2300R/RFS2300R Troubleshooting HEAD SECTION FOR RACK REFRIGERATION SYSTEMS Normal Operation When the toggle switch is placed in the ON position the following controls must be in the closed position before the ice machine will start: Bin Thermostat Ice Chute Safety Switch Low Water Level Switch Placing the toggle switch in the ON position starts the gear motor.
Page 120 Part Number 000007661 Rev02 02/20...
Page 121 Part Number 000007661 Rev02 02/20...
Page 122 Part Number 000007661 Rev02 02/20...
Page 123 Part Number 000007661 Rev02 02/20...
Page 124 Part Number 000007661 Rev02 02/20...
Page 125 Part Number 000007661 Rev02 02/20...
Page 126 Part Number 000007661 Rev02 02/20...
Page 127: Rn0400 Troubleshooting
RN0400 Troubleshooting NOTE: Refer to “RN0400” on page 29 for normal sequence of operation. OVER-TORQUE FAILURE Step 1 The ice machine stops and the 20M light energizes. The PWR, WTR and BE lights remain energized. The ice machine restarts after 20 minutes. Part Number 000007661 Rev02 02/20...
Page 128 Step 2 Successful restart and normal operation - The 20M light de-energizes and the 60M light energizes. After 60 minutes of normal operation the 60M light de- energizes. Part Number 000007661 Rev02 02/20...
Page 129 Step 3 Unsuccessful restart or abnormal operation - The 60M light de-energizes and the 2ND light energizes. The reset button on the control board must be pressed to restart the ice machine. Part Number 000007661 Rev02 02/20...
Page 130: Water Loss Failure
WATER LOSS FAILURE The ice machine stops and the BT light energizes and the WTR light de-energizes. If water is restored the WTR light will flash as an indicator. The flashing WTR light can be cleared by pressing the reset button on the control board. Part Number 000007661 Rev02 02/20...
Page 131 Part Number 000007661 Rev02 02/20...
Page 132 Part Number 000007661 Rev02 02/20...
Page 133 Part Number 000007661 Rev02 02/20...
Page 134 Part Number 000007661 Rev02 02/20...
Page 135 Part Number 000007661 Rev02 02/20...
Page 136: Rn1000/Rn1400 Troubleshooting
RN1000/RN1400 Troubleshooting NOTE: Refer to “RN1000/RN1400” on page 36 for normal sequence of operation INDICATOR LIGHT OPERATION The lights on the control board can be used as quick failure mode indicators. If the failure mode isn’t obvious from the light indicators, use the flowchart to systematically eliminate issues.
Page 137 2. CPU light does not flash • Defective control board 3. In time delay mode and bin is not full • Shuttle is jammed or damaged • Thermostat is out of position or defective 4. Locked in purge cycle, no ice •...
Page 138 5. No ice, Hi Amps and Service lights on • Evaporator dirty • Gear motor not running or intermittent • Does not shut off on full bin condition 6. No ice, Drain Clog and Service lights on • Drain obstructed •...
Page 139 8. No ice, Lo Water light on • No water • Low water pressure • Defective solenoid valve or control board relay Part Number 000007661 Rev02 02/20...
Page 140: Control Board Errors
CONTROL BOARD ERRORS The control board monitors the following: Low water Gear motor amperage High pressure Clogged drain There are two different errors - Soft errors and hard errors. • Soft errors can be reset by cycling power on/off. • Hard errors can not be cleared by cycling power on/ off and must be reset by pressing the control board reset button.
Page 141 HI AMPS - GEAR MOTOR AMPERAGE EXCEEDS 3.8 AMPS Soft Error The control board stops the ice machine, energizes the Hi Amps & Service lights and initiates a time delay period. The ice machine will restart after the 60 minute delay. The ice machine continues to run if amperage remains below 3.8 amps for six hours.
Page 142 Part Number 000007661 Rev02 02/20...
Page 143 Part Number 000007661 Rev02 02/20...
Page 144 Part Number 000007661 Rev02 02/20...
Page 145 Part Number 000007661 Rev02 02/20...
Page 146 Part Number 000007661 Rev02 02/20...
Page 147 Part Number 000007661 Rev02 02/20...
Page 148 Part Number 000007661 Rev02 02/20...
Page 149 Part Number 000007661 Rev02 02/20...
Page 150: Rn1000C/Rn1200C Troubleshooting
RN1000C/RN1200C Troubleshooting NOTE: Refer to “RN1000C/RN1200C” on page 39 for normal sequence of operation INDICATOR LIGHT OPERATION The lights on the control board can be used as quick failure mode indicators. If the failure mode isn’t obvious from the light indicators, use the flowchart to systematically eliminate issues.
Page 151 2. CPU light does not flash • Defective control board 3. In time delay mode and bin is not full • Shuttle is jammed or damaged • Thermostat is out of position or defective 4. Locked in purge cycle, no ice •...
Page 152 5. No ice, Hi Amps and Service lights on • Evaporator dirty • Gear motor not running or intermittent • Does not shut off on full bin condition 6. No ice, Drain Clog and Service lights on • Drain obstructed •...
Page 153 8. No ice, Lo Water light on • No water • Low water pressure • Defective solenoid valve or control board relay Part Number 000007661 Rev02 02/20...
Page 154: Control Board Errors
CONTROL BOARD ERRORS The control board monitors the following: Low water Gear motor amperage High pressure Clogged drain There are two different errors - Soft errors and hard errors. • Soft errors can be reset by cycling power on/off. • Hard errors can not be cleared by cycling power on/ off and must be reset by pressing the control board reset button.
Page 155 Hard Error Gear motor amperage exceeds 3.8 amps a second time, within six hours of the first failure. The ice machine must be reset by pressing the control board reset button. HI PRESSURE Soft Error If the refrigeration pressure exceeds 425 psi (2930 kPa) the ice machine will turn off, energize the Hi Press light and initiate a 60 minute delay period.
Page 156 Part Number 000007661 Rev02 02/20...
Page 157 Part Number 000007661 Rev02 02/20...
Page 158 Part Number 000007661 Rev02 02/20...
Page 159 Part Number 000007661 Rev02 02/20...
Page 160 Part Number 000007661 Rev02 02/20...
Page 161 Part Number 000007661 Rev02 02/20...
Page 162 Part Number 000007661 Rev02 02/20...
Page 163 Part Number 000007661 Rev02 02/20...
Page 164 Part Number 000007661 Rev02 02/20...
Page 165 Part Number 000007661 Rev02 02/20...
Page 166 Part Number 000007661 Rev02 02/20...
Page 167 Part Number 000007661 Rev02 02/20...
Page 168: Component Specifications
Component Specifications BIN THERMOSTAT Model Setting Cut-Out Cut-In RF Models 37°F ±1 43°F ±1 RF0244 / RF0266 3°C ±.1 6°C ±.1 RF0385 / RF0388 RF0399 / RF1200 RF2300 RFS Models RFS0244 RF0644 / RFS1200 RN Models RNS0308 / RNS0385 RF Models 36°F ±1 42°F ±1 RF0300 / RF0600...
Page 169: High Pressure Cutout (Hpco) Control
HIGH PRESSURE CUTOUT (HPCO) CONTROL Model Cut-Out Cut-In RF Models 325 psig ±10 200 psig ±10 RNS0308/RF0644 (2250 kPa ±69) (1379 kPa ±69) RFS Models 22.5 bar ±.69 13.79 bar ±.69 RFS0650/RFS1200 Auto Reset RNS Models RNS0300 / RNS0600 RNS1000 000008557 RF Models 435 psig ±10...
Page 170: Rotation Sensor
ROTATION SENSOR RF0644/RF0650/RF1200/RF2300 RFS0650/RFS1200/RFS2300 RNS0600/RNS1000/RNS1078 Light Definition Yellow Blinking Time Delay Period Yellow Solid Normal Operation Sensing Red Blinking 2 Time Delay Period - First 1 To 7 Faults Flashes Per Second Red Solid Lockout - 8 Consecutive Faults Due To A Speed Fault Remove/Restore Power To Reset Red Blinking...
Page 171: Low Pressure Cutout (Lpco) Control
LOW PRESSURE CUTOUT (LPCO) CONTROL Model Cut-Out Cut-In RF Models 7 psig ±2 36 psig ±2 RF0644 / R0F650 (.5 bar ±.2) (2.5 bar ±.2) RF1200 RFS Models RFS1200 RFS2300C-RCU2375 RNS Models RNS0300 / RNS0600 RNS1000 RF2300 12 psig ±2 Manual Reset (.8 bar ±.2) RF Models...
Page 172: Fan Cycle Control
FAN CYCLE CONTROL Model Cut-Out (Open) Cut-In (Close) RF Models 200 ±5 250 ±5 RF0266 / RF0300 (15.17 bar ±.34) (17.23 bar ±.34) RF0385 / RF0388 RF0399 / RF0644 RF0650 / RF1200 RF2300 RFS Models RFS0300 / RFS0650 RNS Models RNS0244 / RNS0300 RNS0385 / RNS0600 RF Models...
Page 173: Total System Refrigerant Charge
TOTAL SYSTEM REFRIGERANT CHARGE This information is for reference only. Model/Serial plate information overrides information listed in this table. Model Refrigerant Charge RF Flake Models RF0244A 7.5 oz / 210 g RF0266A 7.5 oz / 210 g RF0300A 11.25 oz / 320 g RF0385A 11.25 oz / 320 g RF0388A...
Page 174 RN Nugget Models RN0400 19 oz / 539 g RN1000A 24 oz / 680 g RN1000W 15 oz / 426 g RN1000C 156 oz / 4.42 kg RN1200C 156 oz / 4.42 kg RN1400A 34 oz / 652 g RN1400W 21 oz / 426 g RNS Nugget Models RNS0244...
Page 175: Filter-Driers
FILTER-DRIERS The size of the filter-drier is important. The refrigerant charge is critical. Using an improperly sized filter-drier will cause the ice machine to be improperly charged with refrigerant. Important Driers are covered as a warranty part. The drier must be replaced any time the system is opened for repairs.
Page 176: Total System Refrigerant Charge
Charts Total System Refrigerant Charge Important This information is for reference only. Refer to the ice machine serial number tag to verify the system charge. Serial plate information overrides information listed on this page. Ice Production & Refrigerant Pressure These charts are used as guidelines to verify correct ice machine operation.
Page 177: Rf Flake Models
RF Flake Models RF0244A SELF STORAGE AIR-COOLED Characteristics vary depending on operating conditions. ICE PRODUCTION Air Temperature 24 hour Water Temperature Ice Production 70°F/50°F 182 lbs 21°C/10°C 82 kgs 90°F/70°F 151 lbs 32°C/21°C 68 kgs OPERATING PRESSURES PSIG & kPa Air Temperature Freeze Cycle Entering...
Page 178: Rf0266A
RF0266A SELF STORAGE AIR-COOLED Characteristics vary depending on operating conditions. ICE PRODUCTION Air Temperature 24 hour Water Temperature Ice Production 70°F/50°F 1821lbs 21°C/10°C 82 kgs 90°F/70°F 151 lbs 32°C/21°C 68 kgs OPERATING PRESSURES PSIG & kPa Air Temperature Freeze Cycle Entering Discharge Suction...
Page 179: Rf0300A
RF0300A SELF CONTAINED AIR-COOLED Characteristics vary depending on operating conditions. ICE PRODUCTION Model Air Temperature 24 hour Water Ice Production Temperature 70°F/50°F 311 lbs RF0300 21°C/10°C 141 kgs 90°F/70°F 259 lbs 32°C/21°C 117 kgs 70°F/50°F 384 lbs RFS0300 21°C/10°C 174 kgs 90°F/70°F 286 lbs 32°C/21°C...
Page 180: Rf0385A
RF0385A SELF STORAGE AIR-COOLED Characteristics vary depending on operating conditions. ICE PRODUCTION Air Temperature 24 hour Water Temperature Ice Production 70°F/50°F 329 lbs 21°C/10°C 149 kgs 90°F/70°F 273 lbs 32°C/21°C 124 kgs OPERATING PRESSURES PSIG & kPa Air Temperature Freeze Cycle Entering Discharge Suction...
Page 181: Rf0388A
RF0388A SELF STORAGE AIR-COOLED Characteristics vary depending on operating conditions. ICE PRODUCTION Air Temperature 24 hour Water Temperature Ice Production 70°F/50°F 332 lbs 21°C/10°C 151 kgs 90°F/70°F 270 lbs 32°C/21°C 122 kgs OPERATING PRESSURES PSIG & kPa Air Temperature Freeze Cycle Entering Discharge Suction...
Page 182: Rf0399A
RF0399A SELF STORAGE AIR-COOLED Characteristics vary depending on operating conditions. ICE PRODUCTION Air Temperature 24 hour Water Temperature Ice Production 70°F/50°F 332 lbs 21°C/10°C 151 kgs 90°F/70°F 270 lbs 32°C/21°C 122 kgs OPERATING PRESSURES PSIG & kPa Air Temperature Freeze Cycle Entering Discharge Suction...
Page 183: Rf0644A
RF0644A AIR-COOLED Characteristics vary depending on operating conditions. ICE PRODUCTION Air Temperature 24 hour Water Temperature Ice Production 70°F/50°F 688 lbs 21°C/10°C 312 kgs 90°F/70°F 510 lbs 32°C/21°C 231 kgs OPERATING PRESSURES PSIG & kPa Air Temperature Freeze Cycle Entering Discharge Suction Condenser...
Page 184: Rf0650A
RF0650A AIR-COOLED Characteristics vary depending on operating conditions. ICE PRODUCTION Model Air Temperature 24 hour Water Ice Production Temperature 70°F/50°F 671 lbs RF0650A 21°C/10°C 305 kgs 90°F/70°F 545 lbs 32°C/21°C 248 kgs 70°F/50°F 747 lbs RFS0650A 21°C/10°C 339 kgs 90°F/70°F 540 lbs 32°C/21°C 245kgs...
Page 185: Rf0650W
RF0650W WATER-COOLED Characteristics vary depending on operating conditions. ICE PRODUCTION Model Air Temperature 24 hour Water Ice Production Temperature 70°F/50°F 716 lbs RF0650W 21°C/10°C 325 kgs 90°F/70°F 597 lbs 32°C/21°C 271 kgs 70°F/50°F 726 lbs RFS0650W 21°C/10°C 329 kgs 90°F/70°F 586 lbs 32°C/21°C 266 kgs...
Page 186: Rf1200A
RF1200A AIR-COOLED Characteristics vary depending on operating conditions. ICE PRODUCTION Model Air Temperature 24 hour Water Ice Production Temperature 70°F/50°F 1186 lbs RF1200A 21°C/10°C 538 kgs 90°F/70°F 864 lbs 32°C/21°C 392 kgs 70°F/50°F 1202 lbs RFS1200A 21°C/10°C 545 kgs 90°F/70°F 874 lbs 32°C/21°C 396 kgs...
Page 187: Rf1200W
RF1200W WATER-COOLED Characteristics vary depending on operating conditions. ICE PRODUCTION Model Air Temperature 24 hour Water Ice Production Temperature 70°F/50°F 1204 lbs RF1200W 21°C/10°C 546 kgs 90°F/70°F 1004 lbs 32°C/21°C 455 kgs 70°F/50°F 1339 lbs RFS1200W 21°C/10°C 607 kgs 90°F/70°F 1128 lbs 32°C/21°C 512 kgs...
Page 188: Rf1278C With Rcu1075
RF1278C WITH RCU1075 QUIETQUBE REMOTE AIR COOLED Characteristics vary depending on operating conditions ICE PRODUCTION Air Temperature 24 Hour Water Temperature Ice Production -20°F/50°F 1413 lbs -29°C/10°C 641 kgs 70°F/50°F 1092 lbs 21°C/10°C 495 kgs 90°F/70°F 958 lbs 32°C/21°C 435 kgs 120°F/70°F 603 lbs 49°C/21°C...
Page 189: Rf2300A
RF2300A AIR-COOLED Characteristics vary depending on operating conditions. ICE PRODUCTION Air Temperature 24 hour Water Temperature Ice Production 70°F/50°F 2460 lbs 21°C/10°C 1115 kgs 90°F/70°F 1819 lbs 32°C/21°C 825 kgs OPERATING PRESSURES PSIG & kPa Air Temperature Freeze Cycle Entering Discharge Suction Condenser...
Page 190: Rf2300W
RF2300W WATER-COOLED Characteristics vary depending on operating conditions. ICE PRODUCTION Air Temperature 24 hour Water Temperature Ice Production 70°F/50°F 2608 lbs 21°C/10°C 1183 kgs 90°F/70°F 2201 lbs 32°C/21°C 998 kgs OPERATING PRESSURES PSIG & kPa Air Temperature Freeze Cycle Around Ice Discharge Suction Machine...
Page 191: Rf2378C With Rcu2375
RF2378C WITH RCU2375 QUIETQUBE REMOTE AIR COOLED Characteristics vary depending on operating conditions ICE PRODUCTION Air Temperature 24 Hour Water Temperature Ice Production -20°F/50°F 2403 lbs -29°C/10°C 1090 kgs 70°F/50°F 2063 lbs 21°C/10°C 936 kgs 90°F/70°F 1702 lbs 32°C/21°C 772 kgs 120°F/70°F 1073 lbs 49°C/21°C...
Page 192: Rfs Flake Models
RFS Flake Models RFS0244A SELF STORAGE AIR-COOLED Characteristics vary depending on operating conditions. ICE PRODUCTION Air Temperature 24 hour Water Temperature Ice Production 70°F/50°F 182 lbs 21°C/10°C 82 kgs 90°F/70°F 151 lbs 32°C/21°C 68 kgs OPERATING PRESSURES PSIG & kPa Air Temperature Freeze Cycle Entering...
Page 193: Rfs0300A
RFS0300A SELF CONTAINED AIR-COOLED Characteristics vary depending on operating conditions. ICE PRODUCTION Model Air Temperature 24 hour Water Ice Production Temperature 70°F/50°F 311 lbs RF0300 21°C/10°C 141 kgs 90°F/70°F 259 lbs 32°C/21°C 117 kgs 70°F/50°F 384 lbs RFS0300 21°C/10°C 174 kgs 90°F/70°F 286 lbs 32°C/21°C...
Page 194: Rfs0650A
RFS0650A AIR-COOLED Characteristics vary depending on operating conditions. ICE PRODUCTION Model Air Temperature 24 hour Water Ice Production Temperature 70°F/50°F 671 lbs RFS0650A 21°C/10°C 305 kgs 90°F/70°F 545 lbs 32°C/21°C 248 kgs 70°F/50°F 747 lbs RFS0650A 21°C/10°C 339 kgs 90°F/70°F 540 lbs 32°C/21°C 245kgs...
Page 195: Rfs0650W
RFS0650W WATER-COOLED Characteristics vary depending on operating conditions. ICE PRODUCTION Model Air Temperature 24 hour Water Ice Production Temperature 70°F/50°F 740 lbs RFS0650W 21°C/10°C 335 kgs 90°F/70°F 596 lbs RFS0650W 32°C/21°C 270 kgs OPERATING PRESSURES PSIG & kPa Air Temperature Freeze Cycle Entering Discharge...
Page 196: Rfs1200A
RFS1200A AIR-COOLED Characteristics vary depending on operating conditions. ICE PRODUCTION Model Air Temperature 24 hour Water Ice Production Temperature 70°F/50°F 1186 lbs RF1200A 21°C/10°C 538 kgs 90°F/70°F 864 lbs 32°C/21°C 392 kgs 70°F/50°F 1202 lbs RFS1200A 21°C/10°C 545 kgs 90°F/70°F 874 lbs 32°C/21°C 396 kgs...
Page 197: Rfs1200W
RFS1200W WATER-COOLED Characteristics vary depending on operating conditions. ICE PRODUCTION Model Air Temperature 24 hour Water Ice Production Temperature 70°F/50°F 1204 lbs RF1200W 21°C/10°C 546 kgs 90°F/70°F 1004 lbs 32°C/21°C 455 kgs 70°F/50°F 1339 lbs RFS1200W 21°C/10°C 607 kgs 90°F/70°F 1128 lbs 32°C/21°C 512 kgs...
Page 198: Rfs1278C With Rcu1075
RFS1278C WITH RCU1075 QUIETQUBE REMOTE AIR COOLED Characteristics vary depending on operating conditions ICE PRODUCTION Air Temperature 24 Hour Water Temperature Ice Production -20°F/50°F 1413 lbs -29°C/10°C 641 kgs 70°F/50°F 1092 lbs 21°C/10°C 495 kgs 90°F/70°F 958 lbs 32°C/21°C 435 kgs 120°F/70°F 603 lbs 49°C/21°C...
Page 199: Rfs2300A
RFS2300A AIR-COOLED Characteristics vary depending on operating conditions. ICE PRODUCTION Air Temperature 24 hour Water Temperature Ice Production 70°F/50°F 2301 lbs 21°C/10°C 1044 kgs 90°F/70°F 1665 lbs 32°C/21°C 755 kgs OPERATING PRESSURES PSIG & kPa Air Temperature Freeze Cycle Entering Discharge Suction Condenser...
Page 200: Rfs2300W
RFS2300W WATER-COOLED Characteristics vary depending on operating conditions. ICE PRODUCTION Air Temperature 24 hour Water Temperature Ice Production 70°F/50°F 2608 lbs 21°C/10°C 1183 kgs 90°F/70°F 2201 lbs 32°C/21°C 998 kgs OPERATING PRESSURES PSIG & kPa Air Temperature Freeze Cycle Around Ice Discharge Suction Machine...
Page 201: Rfs2378C With Rcu2375
RFS2378C WITH RCU2375 QUIETQUBE REMOTE AIR COOLED Characteristics vary depending on operating conditions ICE PRODUCTION Air Temperature 24 Hour Water Temperature Ice Production -20°F/50°F 2403 lbs -29°C/10°C 1090 kgs 70°F/50°F 2063 lbs 21°C/10°C 936 kgs 90°F/70°F 1702 lbs 32°C/21°C 772 kgs 120°F/70°F 1073 lbs 49°C/21°C...
Page 202: Rn Nugget Models
RN Nugget Models RN0408A AIR-COOLED Characteristics vary depending on operating conditions ICE PRODUCTION Air Temperature 24 Hour Water Temperature Ice Production 70°F/50°F 385 lbs 21°C/10°C 175 kgs 90°F/70°F 294 lbs 32°C/21°C 133 kgs OPERATING PRESSURES PSIG/kPa Air Temperature Freeze Cycle Around Ice Discharge Suction Pressure...
Page 203: Rn1008A
RN1008A AIR-COOLED Characteristics vary depending on operating conditions 24-HOUR ICE PRODUCTION IN LB/KG Water Temperature Temperature °F/°C Entering 50/10 60/16 70/21 80/27 90/32 Condenser °F/°C 60°F 1135 1070 1015 16°C 70°F 1100 1000 21°C 80°F 27°C 90°F 32°C 100°F 38°C OPERATING PRESSURES PSIG/kPa Air Temperature Freeze Cycle...
Page 204: Rn1009W
RN1009W WATER-COOLED Characteristics vary depending on operating conditions 24-HOUR ICE PRODUCTION IN LB/KG Water Temperature Temperature °F/°C Around Ice 50/10 60/16 70/21 80/27 90/32 Machine °F/°C 60°F 1071 1025 16°C 70°F 1035 21°C 80°F 27°C 90°F 32°C 100°F 38°C OPERATING PRESSURES PSIG/kPa Air Temperature Freeze Cycle Around Ice...
Page 205: Rn1408A
RN1408A AIR-COOLED Characteristics vary depending on operating conditions ICE PRODUCTION Air Temperature 24 Hour Water Temperature Ice Production 50°F/50°F 1528 lbs 10°C/10°C 693 kgs 70°F/50°F 1490 lbs 21°C/10°C 676 kgs 90°F/70°F 1318 lbs 32°C/21°C 598 kgs 110°F/70°F 1019 lbs 43°C/21°C 462 kgs OPERATING PRESSURES PSIG/kPa Air Temperature...
Page 206: Rn1409W
RN1409W WATER-COOLED Characteristics vary depending on operating conditions ICE PRODUCTION Air Temperature 24 Hour Water Temperature Ice Production 50°F/50°F 1581 lbs 10°C/10°C 717 kgs 70°F/50°F 1490 lbs 21°C/10°C 676 kgs 90°F/70°F 1318 lbs 32°C/21°C 598 kgs 110°F/70°F 1100 lbs 43°C/21°C 499 kgs OPERATING PRESSURES PSIG/kPa Air Temperature...
Page 207: Rn1078C With Rcu1075
RN1078C WITH RCU1075 QUIETQUBE REMOTE AIR COOLED Characteristics vary depending on operating conditions ICE PRODUCTION Air Temperature 24 Hour Water Temperature Ice Production -20°F/50°F 1105 lbs -29°C/10°C 501kgs 70°F/50°F 880 lbs 21°C/10°C 399kgs 90°F/70°F 713 lbs 32°C/21°C 323kgs 120°F/70°F 490 lbs 49°C/21°C 222kgs OPERATING PRESSURES PSIG/kPa...
Page 208: Rn1278C With Rcu1275
RN1278C WITH RCU1275 QUIETQUBE REMOTE AIR COOLED Characteristics vary depending on operating conditions ICE PRODUCTION Air Temperature 24 Hour Water Temperature Ice Production -20°F/50°F 1201 lbs -29°C/10°C 545kgs 70°F/50°F 1100 lbs 21°C/10°C 499kgs 90°F/70°F 962 lbs 32°C/21°C 436kgs 120°F/70°F 761 lbs 49°C/21°C 345 kgs OPERATING PRESSURES PSIG/kPa...
Page 209: Rns Nugget Models
RNS Nugget Models RNS0244A SELF STORAGE AIR-COOLED Characteristics vary depending on operating conditions. ICE PRODUCTION Air Temperature 24 hour Water Temperature Ice Production 70°F/50°F 155 lbs 21°C/10°C 70 kgs 90°F/70°F 105 lbs 32°C/21°C 48 kgs OPERATING PRESSURES PSIG & kPa Air Temperature Freeze Cycle Entering...
Page 210: Rns0308A
RNS0308A SELF CONTAINED AIR-COOLED Characteristics vary depending on operating conditions. ICE PRODUCTION Air Temperature 24 hour Water Temperature Ice Production 70°F/50°F 315 lbs 21°C/10°C 143 kgs 90°F/70°F 251 lbs 32°C/21°C 114 kgs * Indicates Preliminary Data OPERATING PRESSURES PSIG & kPa Air Temperature Freeze Cycle Entering...
Page 211: Rns0385A
RNS0385A SELF STORAGE AIR-COOLED Characteristics vary depending on operating conditions. ICE PRODUCTION Air Temperature 24 hour Water Temperature Ice Production 70°F/50°F 270 lbs 21°C/10°C 122 kgs 90°F/70°F 223 lbs 32°C/21°C 101 kgs OPERATING PRESSURES PSIG & kPa Air Temperature Freeze Cycle Entering Discharge Suction...
Page 212: Rns0608A
RNS0608A WATER-COOLED Characteristics will vary depending on operating conditions. ICE PRODUCTION Air Temperature 24 Hour Water Temperature Ice Production 70°F/50°F 591 lbs 21°C/10°C 268 kgs 90°F/70°F 451 lbs 32°C/21°C 204 kgs OPERATING PRESSURES PSIG/kPa Air Temperature Freeze Cycle Around Ice Machine Discharge Suction °F/°C...
Page 213: Rns0609W
RNS0609W WATER-COOLED Characteristics will vary depending on operating conditions. ICE PRODUCTION Air Temperature 24 Hour Water Temperature Ice Production 70°F/50°F 613 lbs 21°C/10°C 278 kgs 90°F/70°F 508 lbs 32°C/21°C 230 kgs OPERATING PRESSURES PSIG/kPa Air Temperature Freeze Cycle Around Ice Machine Discharge Suction °F/°C...
Page 214: Rns1000A
RNS1000A AIR-COOLED Characteristics vary depending on operating conditions ICE PRODUCTION Air Temperature 24 Hour Water Temperature Ice Production 70°F/50°F 1078 lbs 21°C/10°C 489 kgs 90°F/70°F 825 lbs 32°C/21°C 374 kgs OPERATING PRESSURES PSIG/kPa Air Temperature Freeze Cycle Around Ice Discharge Suction Pressure Machine Pressure...
Page 215: Rns1009W
RNS1009W WATER-COOLED Characteristics will vary depending on operating conditions. ICE PRODUCTION Air Temperature 24 Hour Water Temperature Ice Production 70°F/50°F 1158 lbs 21°C/10°C 525 kgs 90°F/70°F 960 lbs 32°C/21°C 435 kgs OPERATING PRESSURES PSIG/kPa Air Temperature Freeze Cycle Around Ice Machine Discharge Suction °F/°C...
Page 216: Rns1078C With Rcu1098
RNS1078C WITH RCU1098 QUIETQUBE REMOTE AIR COOLED Characteristics vary depending on operating conditions ICE PRODUCTION Air Temperature 24 Hour Water Temperature Ice Production -20°F/50°F 1131 lbs -29°C/10°C 513 kgs 70°F/50°F 1131 lbs 21°C/10°C 513 kgs 90°F/70°F 900 lbs 32°C/21°C 408 kgs 120°F/70°F 490 lbs 49°C/21°C...
Page 217: Rack Models
Rack Models RF1279R QUIETQUBE REMOTE AIR COOLED Characteristics vary depending on operating conditions 24-HOUR ICE PRODUCTION IN LB/KG Water Temperature 24 hr Ice Production °F/°C 50°F- 10°C 1092 lbs - 495 kgs 70°F- 21°C 958 lbs - 435 kgs SUCTION PRESSURE PSIG/kPa Freeze Cycle Liquid Line Pressure Acceptable Suction...
Page 218: Rfs1279R
RFS1279R QUIETQUBE REMOTE AIR COOLED Characteristics vary depending on operating conditions 24-HOUR ICE PRODUCTION IN LB/KG Water Temperature 24 hr Ice Production °F/°C 50°F- 10°C 1092 lbs - 495 kgs 70°F- 21°C 958 lbs - 435 kgs SUCTION PRESSURE PSIG/kPa Freeze Cycle Liquid Line Pressure Acceptable Suction...
Page 219: Rf2379R
RF2379R QUIETQUBE REMOTE AIR COOLED Characteristics vary depending on operating conditions 24-HOUR ICE PRODUCTION IN LB/KG Water Temperature 24 hr Ice Production °F/°C 50°F- 10°C 2063 lbs - 936 kgs 70°F- 21°C 1702 lbs - 772 kgs SUCTION PRESSURE PSIG/kPa Freeze Cycle Liquid Line Pressure Acceptable Suction...
Page 220: Rfs2379R
RFS2379R QUIETQUBE REMOTE AIR COOLED Characteristics vary depending on operating conditions 24-HOUR ICE PRODUCTION IN LB/KG Water Temperature 24 hr Ice Production °F/°C 50°F- 10°C 2063 lbs - 936 kgs 70°F- 21°C 1702 lbs - 772 kgs SUCTION PRESSURE PSIG/kPa Freeze Cycle Liquid Line Pressure Acceptable Suction...
Page 221 THIS PAGE INTENTIONALLY LEFT BLANK Part Number 000007661 Rev02 02/20...
Page 222: Wiring Diagrams
Diagrams Wiring Diagrams The following pages contain electrical wiring diagrams. Be sure you are referring to the correct diagram for the ice machine you are servicing. Warning Always disconnect power before working on electrical circuitry. Flake Models RF0244/RF0266/RF0385/RF0388/RF0399 AIR- COOLED Refer to Nameplate for Voltage Rating Part Number 000007661 Rev02 02/20...
Page 223: Wiring Diagram Legend
WIRING DIAGRAM LEGEND RF0244/RNS0244/RF266/RF0385/RNS0385/RF0388/ RF0399 Gear Motor Compressor Condenser fan motor Water Inlet valve Evaporator low temperature safety or Low pressure control Low water level safety Bin thermostat High temperature limit (snap disc) Fan cycle control Water level switch Compressor relay On/Off switch Gear motor centrifugal switch Wire Color Designation...
Page 224: Rf0300 Air-Cooled
RF0300 AIR-COOLED Refer to Nameplate for Voltage Rating Part Number 000007661 Rev02 02/20...
Page 225 WIRING DIAGRAM LEGEND RF0300 Gear Motor Compressor Condenser fan motor Water inlet valve Evaporator low temperature safety Low pressure control Low water level safety Bin thermostat Fan cycle control Water level switch Ice chute safety switch Compressor relay On/Off switch Compressor time delay Gear motor centrifugal switch Compressor time delay by-pass...
Page 226: Rfs0300 Air-Cooled
RFS0300 AIR-COOLED Refer to Nameplate for Voltage Rating Part Number 000007661 Rev02 02/20...
Page 227 WIRING DIAGRAM LEGEND RFS0300 Gear Motor Compressor Fan motor Water inlet valve Low water level switch Bin thermostat Fan cycle control Water level switch Chute safety switch High Pressure Safety Switch On/Off switch Compressor delay timer Low Pressure Safety Switch Compressor time delay by-pass (service staff only) Wire Color Designation White...
Page 228: Rf0650/Rf1200 Air-Cooled
RF0650/RF1200 AIR-COOLED Refer to Nameplate for Voltage Rating Part Number 000007661 Rev02 02/20...
Page 229 WIRING DIAGRAM LEGEND RF0650/RF1200 Gear Motor Compressor Condenser fan motor Water inlet valve Low water level safety Bin thermostat Fan cycle control Contactor Water level switch Ice chute safety switch High pressure cut out Compressor relay On/Off switch Compressor time delay Low pressure cut out Rotation sensor Compressor time delay by-pass...
Page 230: Rfs1200A Air-Cooled
RFS1200A AIR-COOLED Refer to Nameplate for Voltage Rating BU BK BN Part Number 000007661 Rev02 02/20...
Page 231 WIRING DIAGRAM LEGEND RFS1200A Gear Motor Compressor Fan motor Water inlet valve Low water level switch Bin thermostat Fan cycle control Contactor Water level switch Chute safety switch High pressure safety switch On/Off switch Low pressure safety switch Rotation sensor Compressor time delay bypass Solenoid Valve Wire Color Designation...
Page 232: Rf1200 Water-Cooled
RF1200 WATER-COOLED Refer to Nameplate for Voltage Rating Part Number 000007661 Rev02 02/20...
Page 233 WIRING DIAGRAM LEGEND RF1200 WATER-COOLED Gear Motor Compressor Condenser fan motor Water inlet valve Low water level safety Bin thermostat Fan cycle control Contactor Water level switch Ice chute safety switch High pressure cut out Compressor relay On/Off switch Compressor time delay Low pressure cut out Rotation sensor Compressor time delay by-pass...
Page 234: Rfs1200W Water-Cooled
RFS1200W WATER-COOLED Refer to Nameplate for Voltage Rating BK BN Part Number 000007661 Rev02 02/20...
Page 235 WIRING DIAGRAM LEGEND RFS1200W WATER-COOLED Gear Motor Compressor Fan motor Water inlet valve Low water level switch Bin thermostat Fan cycle control Contactor Water level switch Chute safety switch High pressure safety switch On/Off switch Low pressure safety switch Rotation sensor Compressor time delay bypass Solenoid Valve Wire Color Designation...
Page 236: Rf1200C/Rfs1200C Quietqube Head Section
RF1200C/RFS1200C QUIETQUBE HEAD SECTION Refer to Nameplate for Voltage Rating Connections • A, B, & C connect to a remote panel when used - Jumper must be removed when remote panel is used • 1 & 2 connect to line voltage •...
Page 237 WIRING DIAGRAM LEGEND RF1200C/RFS1200C Gear Motor Water inlet valve Low water level safety Bin thermostat Water level switch Ice chute safety switch Compressor Relay On/Off switch Rotation sensor Compressor time delay by-pass Solenoid Valve Wire Color Designation White Blue Grey Brown Black Violet...
Page 238: Rf2300/Rfs2300 Air-Cooled & Water-Cooled
RF2300/RFS2300 AIR-COOLED & WATER-COOLED Refer to Nameplate for Voltage Rating Connections • A & B connect to a remote panel when used - Jumper must be removed when remote panel is used • C & D energize a remote alarm indication when used Part Number 000007661 Rev02 02/20...
Page 239 WIRING DIAGRAM LEGEND RF2300/RFS2300 AIR & WATER COOLED Gear Motor Compressor Condenser fan motor (air-cooled only) Water inlet valve Low water level safety Bin thermostat Fan cycle control Contactor Water level switch Ice chute safety switch High pressure cut out On/Off switch Compressor time delay Low pressure cut out...
Page 240: Rf2378C/Rfs2378C Quietqube Head Section
RF2378C/RFS2378C QUIETQUBE HEAD SECTION Refer to Nameplate for Voltage Rating Connections • A, B, & C connect to a remote panel when used - Jumper must be removed when remote panel is used • 1 & 2 connect to line voltage •...
Page 241 WIRING DIAGRAM LEGEND RF2300C/RFS2300 HEAD SECTION Gear Motor Water inlet valve Low water level safety Bin thermostat Water level switch Ice chute safety switch Compressor Relay On/Off switch Rotation sensor Compressor time delay by-pass Solenoid Valve Wire Color Designation White Blue Grey Brown...
Page 242: Condensing Units
Condensing Units RCU CONDENSING UNIT 1PH Refer to Nameplate for Voltage Rating Part Number 000007661 Rev02 02/20...
Page 243 WIRING DIAGRAM LEGEND RCU CONDENSING UNIT High Pressure Cutout Control Thermostat - Receiver Heater Receiver Heater Low Pressure Cutout Control Contactor Coil Contactor Contacts Condenser Fan Motor Condenser Fan Motor Run Capacitor Compressor Compressor Overload Compressor Run Capacitor Compressor Relay Compressor Start Capacitor Wire Color Designation Black...
Page 244: Rcu Condensing Unit 3Ph
RCU CONDENSING UNIT 3PH Refer to Nameplate for Voltage Rating Part Number 000007661 Rev02 02/20...
Page 245 WIRING DIAGRAM LEGEND RCU CONDENSING UNIT High Pressure Cutout Control Thermostat - Receiver Heater Receiver Heater Low Pressure Cutout Control Contactor Coil Contactor Contacts Condenser Fan Motor Condenser Fan Motor Run Capacitor Compressor Part Number 000007661 Rev02 02/20...
Page 246: Rack Models
Rack Models RF1279R/RFS1279R HEAD SECTION Connections • A, B, & C connect to a remote panel when used - Jumper must be removed when remote panel is used • 1 & 2 connect to line voltage • 3 & 4 energizes remote refrigeration - 2 Amp max Part Number 000007661 Rev02 02/20...
Page 247 WIRING DIAGRAM LEGEND RF1279R Gear Motor Water inlet valve Low water level safety Bin thermostat Water level switch Ice chute safety switch Compressor Relay On/Off switch Rotation sensor Compressor time delay by-pass Suction Line Solenoid Valve Liquid Line Solenoid Valve Wire Color Designation White Blue...
Page 248: Rf2379R/Rfs2379R Head Section
RF2379R/RFS2379R HEAD SECTION Refer to nameplate for voltage Connections • A, B, & C connect to a remote panel when used - Jumper must be removed when remote panel is used • 1 & 2 connect to line voltage • 3 &...
Page 249 WIRING DIAGRAM LEGEND RF2379R Gear Motor Water inlet valve Low water level safety Bin thermostat Water level switch Ice chute safety switch Compressor Relay On/Off switch Rotation sensor Compressor time delay by-pass Suction Line Solenoid Valve Liquid Line Solenoid Valve Wire Color Designation White Blue...
Page 250: Nugget Models
Nugget Models RNS0244/RNS0385 AIR-COOLED Refer to Nameplate for Voltage Rating Part Number 000007661 Rev02 02/20...
Page 251 WIRING DIAGRAM LEGEND RNS0244/RNS0385 Gear Motor Compressor Condenser fan motor Water Inlet valve Evaporator low temperature safety or Low pressure control Low water level safety Bin thermostat High temperature limit (snap disc) Fan cycle control Water level switch Compressor relay On/Off switch Gear motor centrifugal switch Wire Color Designation...
Page 252: Rns0308 Air-Cooled
RNS0308 AIR-COOLED Refer to Nameplate for Voltage Rating Part Number 000007661 Rev02 02/20...
Page 253 WIRING DIAGRAM LEGEND RNS0308 Gear Motor Compressor Condenser fan motor Water inlet valve Evaporator low temperature safety Low water level safety Bin thermostat Fan cycle control Water level switch Ice chute safety switch Compressor relay On/Off switch Compressor time delay Gear motor centrifugal switch Compressor time delay by-pass Wire Color Designation...
Page 254: Rn0400 115V/60Hz/1Ph
RN0400 115V/60HZ/1PH Part Number 000007661 Rev02 02/20...
Page 255: Rn0400 230V/60Hz/1Ph
RN0400 230V/60HZ/1PH VIOLET VIOLET WHITE BLACK BLACK BLUE Part Number 000007661 Rev02 02/20...
Page 256: Rns0600A Air-Cooled
RNS0600A AIR-COOLED Refer to Nameplate for Voltage Rating BK BN Part Number 000007661 Rev02 02/20...
Page 257 WIRING DIAGRAM LEGEND RNS0600A Gear Motor Compressor Condenser fan motor Water inlet valve Low water level safety Bin thermostat Fan cycle control Contactor Water level switch Ice chute safety switch High pressure cut out On/Off switch Low pressure cut out Rotation sensor Compressor time delay by-pass Wire Color Designation...
Page 258: Rns0600W Water-Cooled
RNS0600W WATER-COOLED Refer to Nameplate for Voltage Rating Part Number 000007661 Rev02 02/20...
Page 259 WIRING DIAGRAM LEGEND RNS0600W Gear Motor Compressor Water inlet valve Low water level safety Bin thermostat Contactor Water level switch Ice chute safety switch High pressure cut out On/Off switch Low pressure cut out Rotation sensor Compressor time delay by-pass Wire Color Designation White Blue...
Page 260: Rns1000 Air-Cooled
RNS1000 AIR-COOLED Refer to Nameplate for Voltage Rating Part Number 000007661 Rev02 02/20...
Page 261 WIRING DIAGRAM LEGEND RNS1000 Gear Motor Compressor Condenser fan motor Water inlet valve Low water level safety Bin thermostat Fan cycle control Contactor Water level switch Ice chute safety switch High pressure cut out Compressor relay On/Off switch Compressor time delay Low pressure cut out Rotation sensor Compressor time delay by-pass...
Page 262: Rns1009 Water-Cooled
RNS1009 WATER-COOLED Refer to Nameplate for Voltage Rating Part Number 000007661 Rev02 02/20...
Page 263 WIRING DIAGRAM LEGEND RNS1009 WATER-COOLED Gear Motor Compressor Fan Motor Water inlet Valve Low Water Level Switch Bin Thermostat Fan cycle control Contactor Water level switch Chute safety switch High pressure safety switch On/Off switch Low pressure safety switch Rotation sensor Compressor time delay by-pass (Service staff only) Solenoid Valve Wire Color Designation...
Page 264: Rns1078C
RNS1078C Refer to Nameplate for Voltage Rating Connections • A, B, & C connect to a remote panel when used, or junction block located on top of junction box. Jumper must be removed when remote panel is used • 1 & 2 connect to line voltage junction box on rear of ice machine - Red wire to L1, Black wire to L2 3 &...
Page 265 WIRING DIAGRAM LEGEND RNS1078C Gear Motor Water inlet valve Low water level switch Bin thermostat Water level switch Chute safety switch Relay On/Off switch Rotation sensor Compressor time delay by-pass (Service Staff only) Solenoid Valve Wire Color Designation Orange White Blue Grey Brown...
Page 266: Rn1000/Rn1400 Air & Water Cooled
RN1000/RN1400 AIR & WATER COOLED Refer to Nameplate for Voltage Rating CPU (G) LO WATER (R) HI WATER (R) DRAIN CLOG (R) LO PRESS (R) CONTROL PC BOARD HI PRESS (R) HI AMPS (R) SERVICE (R) PURGE (Y) CLEANING (Y) TIME DELAY (Y) REFRIG ON (G) AUGER ON (G)
Page 267: Rn1000C/Rn1200C Quietqube Head Section
RN1000C/RN1200C QUIETQUBE HEAD SECTION Refer to Nameplate for Voltage Rating CPU (G) LO WATER (R) HI WATER (R) DRAIN CLOG (R) CONTROL PC BOARD LO PRESS (R) HI PRESS (R) HI AMPS (R) SERVICE (R) PURGE (Y) CLEANING (Y) TIME DELAY (Y) REFRIG ON (G) AUGER ON (G) LOW BIN (G)
Page 268: Refrigeration Tubing Schematics
Refrigeration Tubing Schematics Flake Models RF0244/RFS0244/RF0266/RF0300/RF0385/RF0388/ RF0399/RF0644/RF0650 TUBING DIAGRAM LEGEND Compressor Condenser Liquid Line Drier Capillary tube Accumulator Heat Exchanger Evaporator Part Number 000007661 Rev02 02/20...
Page 269: Rf1200/Rfs1200 Air-Cooled
RF1200/RFS1200 AIR-COOLED TUBING DIAGRAM LEGEND Compressor Condenser Liquid Line Drier Liquid Line Solenoid Valve Suction Accumulator Thermostatic Expansion Valve Liquid Accumulator Evaporator Part Number 000007661 Rev02 02/20...
Page 270: Rf1200/Rfs1200 Water-Cooled
RF1200/RFS1200 WATER-COOLED Part Number 000007661 Rev02 02/20...
Page 271 TUBING DIAGRAM LEGEND Compressor Condenser Liquid Line Drier Liquid Line Solenoid Valve Suction Accumulator Thermostatic Expansion Valve Liquid Accumulator Evaporator Part Number 000007661 Rev02 02/20...
Page 272: Rf2300/Rfs2300 Air-Cooled
RF2300/RFS2300 AIR-COOLED Part Number 000007661 Rev02 02/20...
Page 273 TUBING DIAGRAM LEGEND Compressor Condenser Liquid Line Drier Liquid Line Solenoid Valve Suction Accumulator Thermostatic Expansion Valve Liquid Accumulator Evaporator Part Number 000007661 Rev02 02/20...
Page 274: Rf2300/Rfs2300 Water-Cooled
RF2300/RFS2300 WATER-COOLED Part Number 000007661 Rev02 02/20...
Page 275 TUBING DIAGRAM LEGEND Compressor Condenser Liquid Line Drier Liquid Line Solenoid Valve Suction Accumulator Thermostatic Expansion Valve Liquid Accumulator Evaporator Part Number 000007661 Rev02 02/20...
Page 276: Rf1200C/Rfs1200C Quietqube Head Section
RF1200C/RFS1200C QUIETQUBE HEAD SECTION & RCU1075 CONDENSING UNIT Part Number 000007661 Rev02 02/20...
Page 277 TUBING DIAGRAM LEGEND Compressor Check Valve Head Pressure Control Valve Condenser (air or water cooled) Receiver Condensing unit Liquid Line Drier Liquid Line Shut-off Valve Ice Machine Liquid Line Drier Liquid Line Solenoid Valve Thermostatic Expansion Valve Evaporator Suction Line Shut-off Valve Suction Line Filter Suction Accumulator Part Number 000007661 Rev02 02/20...
Page 278: Rf2300C/Rfs2300 Quietqube Head Section
RF2300C/RFS2300 QUIETQUBE HEAD SECTION & RCU2375 CONDENSING UNIT Part Number 000007661 Rev02 02/20...
Page 279 TUBING DIAGRAM LEGEND Compressor Check Valve Head Pressure Control Valve Condenser (air or water cooled) Receiver Condensing unit Liquid Line Drier Liquid Line Shut-off Valve Ice Machine Liquid Line Drier Liquid Line Solenoid Valve Thermostatic Expansion Valve Evaporator Liquid Accumulator Suction Line Shut-off Valve Suction Line Filter Suction Accumulator...
Page 280: Nugget Models
Nugget Models RN0244/RNS0244/RN0385/RNS0385 Air & Water-cooled TUBING DIAGRAM LEGEND Compressor Condenser (air or water cooled) Liquid Line Drier Heat Exchanger Capillary Tube Evaporator Part Number 000007661 Rev02 02/20...
Page 281: Rns0308
RNS0308 TUBING DIAGRAM LEGEND Compressor Condenser (air or water cooled) Liquid Line Drier Heat Exchanger Automatic Expansion Valve Evaporator Part Number 000007661 Rev02 02/20...
Page 282: Rn0400/Rn1000/Rn1400 Air & Water-Cooled
RN0400/RN1000/RN1400 AIR & WATER-COOLED Part Number 000007661 Rev02 02/20...
Page 283 TUBING DIAGRAM LEGEND Compressor Condenser (air or water cooled) Liquid Line Drier Heat Exchanger Thermostatic Expansion Valve Evaporator Part Number 000007661 Rev02 02/20...
Page 284: Rn1000C/Rn1200C Quietqube Head Section & Rcu1075/Rcu1275 Condensing Unit
RN1000C/RN1200C QUIETQUBE HEAD SECTION & RCU1075/RCU1275 CONDENSING UNIT Part Number 000007661 Rev02 02/20...
Page 285 TUBING DIAGRAM LEGEND Compressor Check Valve Head Pressure Control Valve Condenser (air or water cooled) Receiver Condensing unit Liquid Line Drier Liquid Line Shut-off Valve Ice Machine Liquid Line Drier Liquid Line Solenoid Valve Thermostatic Expansion Valve Evaporator S Trap (20’ + Rise Only) Suction Line Shut-off Valve Suction Line Filter Suction Accumulator...
Page 286 Part Number 000007661 Rev02 02/20...
Page 287 THIS PAGE INTENTIONALLY LEFT BLANK Part Number 000007661 Rev02 02/20...
Page 288 MANITOWOC ICE 2110 SOUTH 26TH STREET MANITOWOC, WI 54220 800-545-5720 WWW.MANITOWOCICE.COM ©2020 Manitowoc Ice except where explicitly stated. All rights reserved. Part Number 000007661 Rev02 02/20...

Manitowoc RFS Series Technician's Handbook

Quick Links

Troubleshooting

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Manitowoc RFS Series

Summary of Contents for Manitowoc RFS Series

This manual is also suitable for:
