WIRING DIAGRAM LEGEND
RNS0244/RNS0385
1
2
4
6
7
10
11
12
13
17
21
24
26
B
BL
G
M
N
R
RS
Part Number 000007661 11/16
Gear Motor
Compressor
Condenser fan motor
Water Inlet valve
Evaporator low temperature safety or
Low pressure control
Low water level safety
Bin thermostat
High temperature limit (snap disc)
Fan cycle control
Water level switch
Compressor relay
On/Off switch
Gear motor centrifugal switch
Wire Color Designation
White
Blue
Grey
Brown
Black
Red
Pink
