Software Style - biochrom Novaspec III Plus Manual

Software Style

The user interface is built around the options key
application and you will use the options key to select different parameters.
Keypad Number
1 Parameter
2 Print
3 Graph
4 Run Standard
5 Utilities
6 Methods
7 Sample Number
8 Save Method
9 Auto-Print
. The instrument will open automatically to an
Allows you to run in different modes: Absorbance, Transmission,
Concentration with Factor, Concentration with Standard, Rate
(Kinetics)
Export results via the selected method.
Allows you to toggle back and forth between how the results are
given, digital versus a graph.
Allows you to measure your standard when in Concentration
Standard measurement mode.
Instrument set up (date, time, language, data output,
preferences and display settings).
Sub folder selection or user selected and configured method (8
sub folders each containing a maximum of 9 methods). To
return to the previous measurement mode, select the methods
followed by "Esc" button.
Allows you to name your sample manually or can be prompted.
Use the left and right arrow key to select a folder to store in and
using the alphanumeric keypad to name your method.
Toggles auto-print on/off.
Description
9 | P a g e
