Icon Glossary

Status Bar Icons Meaning
Display and
Menu Icons
Measurement in progress (lamp lit). The icons are cycled through to indicate the lamp
coming up to full brightness and then shown in reverse when the lamp is turned off.
Heated cell holder at temperature.
Heated cell holder fitted but not enabled.
Heated cell holder heating.
Heated cell holder cooling.
Heated cell holder error.
Auto print off i.e. no icon just blank.
Auto print via USB to PC enabled.
Auto print to USB memory stick enabled.
USB memory stick insertion detected.
"Printing" to USB memory stick in progress.
"Printing" via USB to PC in progress.
Rate/kinetics inter-measurement delay.
Meaning
About - used to view unit identification information.
Date and time setup.
Display setup settings of contrast and brightness.
39 | P a g e
