Transmission
Step 1
Press the Options Key
.
Step 2
Press 1 to set parameters.
Step 3
If not already in Transmission mode, use the left
and right arrow keys to choose Transmission
mode.
Press the down arrow key.
Step 4
Use the left and right arrow keys to change the
wavelength, or use the number keypad.
Press the down arrow key.
Step 5
If required enter a sample name. This name
followed by an incrementing sample number will
be used for naming subsequent results.
Press the down arrow key.
Step 6
Set this option to yes, if you need to measure
many different samples and assign different
sample names. The prompt will, by default,
contain the sample name last entered.
Press the down arrow key.
Step 7
Press ok
when all parameters have been
entered.
13 |
P a g e
