Keypad and Display

The back-lit liquid crystal display is very easy to navigate around using the alphanumeric entry and navigation arrow keys
on the hard wearing, spill proof membrane keypad.
On/Standby
Key
Arrow Keys
Key
On/Standby
Key
Arrow Keys
View Options
Alphanumeric
Keys
Escape/
Cancel
OK
Set
Reference
Take a
Measurement
View Options
Turns the instrument on or back to standby.
Use the four arrow keys to navigate around the display and select the required
setting for the active (highlighted) option.
Used to view current options.
Used to select items in a menu or to enter parameters and text descriptions
where. Repeated key presses can be used to cycle through lower case, upper
case, and numbers. Wait 1 second before entering the next character. Use the
C key to backspace and the 1 key to enter a space.
Escape from a selection and return to the previous screen.
Confirm parameters/selection.
Set reference to 0.000A or 100%T on a reference solution at the current
wavelength in the measurement mode selected. When in scan mode, do a
reference scan.
Take a measurement.
Alphanumeric Keys
Escape/Cancel
OK Key
Set Reference
Take a Measurement
Action
