H MPR30 RX M
OW TO USE
Wisycom MPR30 RX Manager can be used to load or save the channels memory and upgrade
the firmware.
Instruction to connect MPR30 using UPK300 / UPK300E
1. Connect to the PC the infrared programming interface (UPK300 or UPK300E) using a
USB cable (NOTE: it is not possible to use IR interface of MRK950 or MRK960)
2. Check if the version of ENG RX Manager installed in your PC is the latest version. If
not, uninstall the ENG RX Manager actives in your PC and install the new version as
indicated in the section
3. Run ENG RX Manager
4. Power up the receiver MPR30 and enable the IRDA interface:
a. push
b. push
(Headphones>Edit RX>Display>Infrared)
c. push again
5. Put in contact MPR30 and UPK300/UPK300E
6. Push Disconnected button. On the Device connection windows select UPK port and
verify that upk300 is
selected on the
Silabs USB devices
panel. If upk300
device is not
showed, push
Refresh button
and/or try to
disconnect and
reconnect the USB
cable connected to
ANAGER
How to update ENG RX Manager
button,
button until that Infrared submenu appears on the display
button and check the display shows 'IR IF active'
Pag. 1
MPR30 Manager
.
:
