WisyCom MPR30-ENG User Manual

High performance true diversity camera receiver
Hide thumbs Also See for MPR30-ENG:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Manual
MPR30-ENG User Manual
High performance
True diversity
Camera Receiver
SN: ________________
Rev. 14 (rif. FW v1.11)
Date: 15 April 2015

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MPR30-ENG and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for WisyCom MPR30-ENG

Summary of Contents for WisyCom MPR30-ENG

  • Page 1 MPR30-ENG User Manual High performance True diversity Camera Receiver SN: ________________ Rev. 14 (rif. FW v1.11) Date: 15 April 2015...
  • Page 2 Rev. 14 MPR30-ENG User Manual...

  • Page 3: Brief Description

    MPR30-ENG User Manual RIEF DESCRIPTION MPR30-ENG is a compact true diversity receiver designed for professional ENG, broadcast, and field production applications. This receiver features a real TRUE DIVERSITY configuration along with a unique wide-band tuning range up to 232 MHz.

  • Page 4: Safety Instruction

    Rev. 14 MPR30-ENG User Manual Above a schematic with an overview of main receiver functions. AFETY INSTRUCTION  Read this safety instruction and the manual first  Follow all instructions and information.  Do not lose this manual.  Do not use this apparatus under the rain or near the water.
  • Page 5 Charging of lithium-ion rechargeable batteries can be done with dedicated charger thru the integrated micro-usb-B connector thru 5 pin mini-XLR male connector (only for MPR30-ENG-5PW model) For B and C items, the charging status can be checked looking the status of LED indicator...
  • Page 6 Rev. 14 MPR30-ENG User Manual RONT ANEL ONTROL AND UNCTIONS MPR30-ENG allows an easy and quick configuration using buttons, RGB LED’s and an OLED display. OLED Display ON Led Indicator RF Led Indicator SYNC/UP SCAN/DOWN Button POWER/EXIT MENU/SELECT Button Button...
  • Page 7 *DISPLAY indicate the state of OLED display before the OFF timeout ** to put the MPR30-ENG in boot mode: power on the device push and keep both UP and DOWN buttons for few seconds (until the led indicators light up, then release the buttons)

  • Page 8: Upper Panel

    Rev. 14 MPR30-ENG User Manual When a Wisycom transmitter, with PTT Mode parameter set to Normal, is received to the MPR30-ENG, the batteries status of the transmitter is received and showed from the MPR30- ENG on the OLED display (see status menu) and on the RF led indicator.
  • Page 9 Rev. 14 MPR30-ENG User Manual Line Output The audio LINE output balanced on 3 pin mini-XLR male connector 5 pin mini-XLR male connector FRONTVIEW FRONTVIEW FRONTVIEW FRONTVIEW mini xlr 3 pin mini xlr 5 pin mini xlr 3 pin mini xlr 5 pin...
  • Page 10 Rev. 14 MPR30-ENG User Manual ISPLAY Min, -72dB ÷ 5dB, Max Headphone GR: 00 ÷ 39 GR-CH CH: 00 ÷ 59 N: 470.000÷700.000 Freq M: 566.000÷798.000 J: 712.000÷832.000 OFF, 0 dBµV ÷ 46dBµV Squelch ENR Wis / ENC Wis / ENR-1.2 / ENC-1.2 Expander Tone sq.

  • Page 11: Status Menu

    NOTE: in case of absence of tone squelch and RF level < Squelch, the symbol will be display batteries level for  R = MPR30-ENG receiver and  T = Wisycom transmitter: when the rx is tuned with a Wisycom transmitter with PTT Mode parameter set to Disable/Normal/Muting...
  • Page 12 Rev. 14 MPR30-ENG User Manual Headphones menu Cycle through menu’s with up/down arrow to get your desired headphones output level from Max (+6 dB) to min (-72 dB) in 1 dB step then confirm with SEL. Edit RX menu Selecting this sub-menu most of RX1 setups are configurable Edit RX menu >...
  • Page 13 Rev. 14 MPR30-ENG User Manual Edit RX menu > Expander submenu MPR30-ENG core is a power digital audio processor that, besides an unbeatable audio quality and flexibility, can emulate most companders systems on the market. On this menu you can setup the audio companding chipset emulation.
  • Page 14 MPR30-ENG User Manual Edit RX menu > Tone sq. submenu MPR30-ENG is able to detect a digital tone squelch generated by a Wisycom transmitters Tone squelch ON: when the tone squelch is enabled the audio is muted unless the correct carrier is detected. Tone...
  • Page 15 From the transmitter it’s possible to see the graphic of the last scan and choose the frequency to tune. (*)As per Wisycom standard, group 00 and group 01 or 09 are special; respectively the “center frequency” (474,482/… MHz) and the intergap frequency (i.e. 470/478/486/… MHz). A scan on...
  • Page 16 Rev. 14 MPR30-ENG User Manual “Scan now” menu The following table lists the three types of scans that can be performed Once started a Channel scan operation the receiver asks for group to be used*. Press and hold the SEL button to select the group to scan.
  • Page 17 Rev. 14 MPR30-ENG User Manual So press SEL to start the scan! After few seconds, scan results are displayed on a histogram. Each column of the histogram is divided into two parts by a black line. The lower part indicates the number of free channels (RF level <...

  • Page 18: Settings Menu

    Rev. 14 MPR30-ENG User Manual Edit RX menu > Cal.Tone submenu Calibration Tone function generates a 1 KHz sine audio at the audio outputs (LINE and headphone) at the level selected (-18dB or 0dB). Select the level and push SEL Button to start calibration tone function.
  • Page 19 Alarm: LED indicators lights up only when an alarm happened OFF: LED indicators remain off Infrared menu By this menu, MPR30-ENG can be connected to IRDA for setup or firmware upgrades. NOTE: while in this menu display is not automatically turned off.

  • Page 20: Preset Menu

    Rev. 14 MPR30-ENG User Manual Info menu The INFO function shows many important features or information of MPR30 receiver: PARAMETER MEANING example Model Wisycom receiver model MPR30-ENG Range Frequencies range of working 566-798 Serial Serial number S1733185 Version * Firmware version v1.09...

  • Page 21: Alarm List

    When the alarm is solved, the message on the display disappear, while the alarm information (counter and alarm type on the list) remains in memory (To reset the error counter and the alarms list, it is necessary to contact Wisycom. Message on display...

  • Page 22: Troubleshooting

    MPR30-ENG User Manual Troubleshooting Alarms Alarm description throubleshooting Error during the power on phase: invalid - send to repair at Wisycom Invalid DSP App DSP application Repair Centre Error during the power on phase: invalid - send to repair at Wisycom...

  • Page 23: Optional Accessories And Parts

    Rev. 14 MPR30-ENG User Manual OPTIONAL ACCESSORIES AND PARTS Depending on the working band there are 3 types of MPR30-ENG: ● MPR30-ENG-N = 470 ÷ 700 MHz ● MPR30-ENG-M = 566 ÷ 758 MHz ● MPR30-ENG-J = 712 ÷ 832 MHz...
  • Page 24 Rev. 14 MPR30-ENG User Manual MPR30 RX M OW TO USE ANAGER Wisycom MPR30 RX Manager can be used to load or save the channels memory and upgrade the firmware. Instruction to connect MPR30 using UPK300E/UPK Mini Mini Connect to the PC the infrared programming interface (UPK300E or UPK...
  • Page 25 Rev. 14 MPR30-ENG User Manual If the connection is ended well, the Connected icon is showed on the top of the panel and “Connected on USB by UPK” is displayed on the information panel...
  • Page 26 Rev. 14 MPR30-ENG User Manual Instruction to connect MPR30 using USB cable: In order to use the micro USB port to configure the MPR30, it is necessary to install the MPR30 USB driver (see How to install MPR30 USB driver)

  • Page 27: How To Upgrade The Firmware

    Rev. 14 MPR30-ENG User Manual How to load/save channels memory Write: Push the button Write from WDF file… and select the wdf file to load on the MPR30. Read and save: Push the button Read and save to WDF file… , insert the .wdf file name and the path where to save the wdf file.

  • Page 28: Technical Specifications

    • IIP3 : > +6 dBm typical. • Spurious emissions : < 2 nW (typical = 0.1 pW). : DSP programmable  ENR (Wisycom Extended-NR) • Noise Reduction  ENC (Wisycom High fidelity) other emulations available for PH.472/PH.475/RMS based expander •...

  • Page 29: Mechanical Drawing

    CAN RSS-Gen/CNR-Gen 5-pin option models: ● MPR30-ENG-5PW: through the power supply V+= 5V (pin 4 of mini XLR), the battery is charged (if you insert a rechargeable lithium-ion battery). We advisable not to use the receiver while charging the battery.
  • Page 30 Rev. 14 MPR30-ENG User Manual...
  • Page 31 Rev. 14 MPR30-ENG User Manual ITALY ONLY Obblighi di informazione agli utilizzatori Modello di informazioni agli utenti dei prodotti di tipo “professionale” INFORMAZIONE AGLI UTENTI ai sensi dell’art. 13 del Decreto Legislativo 25 luglio 2005, n. 151 “Attuazione delle Direttive 2002/95/CE, 2002/96/CE e 2003/108/CE, relative alla riduzione dell’uso di sostanze pericolose nelle apparecchiature...
  • Page 32 Rev. 14 MPR30-ENG User Manual Wireless System Communications Via Spin 156  I-36060 Romano d’Ezzelino  Italia Tel. +39 -0424 -382605  Fax +39 - 0424 - 382733  e-mail: sales@wisycom.com www.wisycom.com...
