f.
Close SW5 of the ground closure again.
g. Verify that the oscilloscope displays the waveform as shown in Figure
B-29.
4. Push the CH1 OUT button to turn off the CH1 LED.
5. Disconnect the oscilloscope and ground closure.
Appendix B: Performance Verification (AWG710B)
B-45
