Table 3-45: Diagnostic categories and error codes

Categories
Calibration
System
Run mode
Clock
AWG710&AWG710B Arbitrary Waveform Generator User Manual
Error codes Descriptions
1101 to 1104 Internal offset calibration error
1201 to 1204 Output offset calibration error
1301 to 1304 Gain calibration error
1401 to 1404 Gain difference calibration error
1501 to 1504 Direct out calibration error
1601 to 1604 Attenuator calibration error
1611 to 1614 5dB attenuator 1 calibration error
1621 to 1624 5dB attenuator 2 calibration error
1631 to 1634 10dB attenuator calibration error
1641 to 1644 20dB attenuator calibration error
1701 to 1704 Filter calibration error
1711 to 1714 20MHz filter calibration error
1721 to 1724 50MHz filter calibration error
1731 to 1734 100MHz filter calibration error
1741 to 1744 200MHz filter calibration error
1801 to 1804 Reference level error
2100 System test error
2101 Real–time clock power test error
2102 Configuration record, checksum status error
2103 Incorrect configuration
2104 Memory size test error
2105 Fixed–disk drive initialization status error
2106 Time status error
2110 to 2116 Front–panel test error
2700 to 2703 Calibration data test error
3000 Run mode test error
3100 Run mode control register 0 test error
3101 to 3108 Run mode control register test error (reg0 to
reg7)
3200 Run mode control register 1 test error
3201 Run mode control register 1 reg0
3211 Run mode control register 1 reg10
4000 Clock test error
4100 PLL lock/unlock test error
