Specifications

Display Type
Display Color
Screen Resolution
Brightness
Dimensions
Display Size
Weight
Power @ Amp
Video Type Supported
Video Sources
Screen Control
Viewing Angle
Materials
Remote Control
Pixel Pitch
Operating Temperature
Additional Test Certifications

Installation Instructions

All cabin equipment, such as the FD220CV-C-1, should be installed on a non-essential bus
and have a dedicated circuit breaker. It is a requirement that a switch be installed in the
cockpit so that the pilot can de-energize the system should it become necessary.
There are (10) 8-32 UNC mounting holes located on the sides and back of the display. Six
mounting points are located on the rear and two on each side of the bezel. See installation
drawing at end of manual for dimensional details.

Power

This is a 28VDC monitor that requires 1.94 Amps of maximum continuous steady-state
power to operate. The unit turns on automatically upon power application.
© 2017 FDS Avionics Corp.
All Rights Reserved.
Document Number:
MAN – FD220CV-C-1
21.5" TFT Color LCD
16.7 Million Colors
1920 x 1080
300 cd/m
19.5"(W) x 11.5" (H) x 1.675"(D)
18.75"(W) x 10.55"(H)
9.75 Lb.
28V DC @ 1.94A Max. Cont. steady-
state
NTSC/PAL
HD-SDI (In-Out), DVI-D, Industry
Standard VGA, S-Video, Composite
On Screen Display Menu
178° on Both Axis
Aluminum
IR, included
248.25 x 248.25 mm
0-50° C (32-122° F)
FD220CV: DO-160, Sec 21, Cat M
DO-160 Sec 21, Cat B
CSA – C22.2 No. 228-92/UL1418 -
DO-160, Sec 7, Cat B
Rev:
C
2
