10. Technical Data

10.1. Environmental
Ambient temperature range: Operational
Max altitude for rated operation
Relative Humidity
Note : Drive must be Frost and moisture free at all times
Installation above 2000m is not UL approved
10.2. Input / Output Power and Current ratings
The following tables provide the output current rating information for the various Optidrive P2 models. Invertek Drives always recommend that
selection of the correct Optidrive is based upon the motor full load current at the incoming supply voltage.
10.2.1. 200 – 240 Volt (+/- 10%), 1 Phase Input, 3 Phase Output
Frame Power Rating
Size
kW HP
2 0.75 1
2 1.5 1.5
2 2.2 1.5
Note
 Ratings shown above apply to 40°C Ambient temperature. For derating information, refer to section 10.4.1
 The maximum motor cable length stated applies to using a shielded motor cable. When using an unshielded cable, the maximum cable
length limit may be increased by 50%. When using the Invertek Drives recommended output choke, the maximum cable length may be
increased by 100%
 The PWM output switching from any inverter when used with a long motor cable length can cause an increase in the voltage at the motor
terminals, depending on the motor cable length and inductance. The rise time and peak voltage can affect the service life of the motor.
Invertek Drives recommend using an output choke for motor cable lengths of 50m or more to ensure good motor service life
 For UL compliant installation, use Copper wire with a minimum insulation temperature rating of 70°C, UL Class CC or Class J Fuses
10.2.2. 200 – 240 Volt (+/- 10%), 3 Phase Input, 3 Phase Output
Frame Power Rating
Size
kW HP
2 0.75 1
2 1.5 2
2 2.2 3
3 4 5
3 5.5 7.5
4 7.5 10
4 11 15
5 15 20
5 18.5 25
6 22 30
6 30 40
6 37 50
6 45 50
7 55 50
7 75 50
Note
 Ratings shown above apply to 40°C Ambient temperature. For derating information, refer to section 10.4.1
 Operation with single phase supply is possible, with 50% derating of the output current capacity
 The maximum motor cable length stated applies to using a shielded motor cable. When using an unshielded cable, the maximum cable
length limit may be increased by 50%. When using the Invertek Drives recommended output choke, the maximum cable length may be
increased by 100%
 The PWM output switching from any inverter when used with a long motor cable length can cause an increase in the voltage at the motor
terminals, depending on the motor cable length and inductance. The rise time and peak voltage can affect the service life of the motor.
Invertek Drives recommend using an output choke for motor cable lengths of 50m or more to ensure good motor service life
 For UL compliant installation, use Copper wire with a minimum insulation temperature rating of 70°C, UL Class CC or Class J Fuses
