The "Selected Speed Reference" referred to in the above table is determined by the value set in P1-12 (Control Mode) :
P1-12 (control Mode)
0 : Terminal Mode
1 : Keypad Mode (uni-directional)
2 : Keypad Mode (bi-directional)
3 : User PID mode
4 : Fieldbus Control
5 : Slave Mode
Note
1) To access P8-11, set P1-14 = 201
2) If a motor thermistor (PTC type only, or normally closed thermal switch contact) is to be connected, this must be selected in P2-33.
Connect the thermistor between terminal 1 and terminal 10.
3) When P1-12 = 0 and P 1-13 = 10 or 20, the Motorised Pot / Keypad reference is automatically selected to be the Selected Speed
Reference
36
Optidrive ODP-2 User Guide Revisions 2.10
Selected Speed Reference
Analog input 1
Digital Potentiometer
Digital Potentiometer
PID controller output
Speed reference via Fieldbus
Speed reference via Optibus
