10.2.3. 380 – 480 Volt (+ / - 10%), 3 Phase Input, 3 Phase Output
Frame Power Rating
Size
kW HP
2 0.75 1
2 1.5 2
2 2.2 3
2 4 5
3 5.5 7.5
3 7.5 10
3 11 15
4 15 20
4 18.5 25
4 22 30
5 30 40
5 37 50
6 45 60
6 55 75
6 75 100
6 90 150
7 110 175
7 132 200
7 160 250
8 200 300
8 250 350
Note
 Ratings shown above apply to 40°C Ambient temperature. For derating information, refer to section 10.4.1
 Operation with single phase supply is possible, with 50% derating of the output current capacity
 The maximum motor cable length stated applies to using a shielded motor cable. When using an unshielded cable, the maximum cable
length limit may be increased by 50%. When using the Invertek Drives recommended output choke, the maximum cable length may be
increased by 100%
 The PWM output switching from any inverter when used with a long motor cable length can cause an increase in the voltage at the motor
terminals, depending on the motor cable length and inductance. The rise time and peak voltage can affect the service life of the motor.
Invertek Drives recommend using an output choke for motor cable lengths of 50m or more to ensure good motor service life
 For UL compliant installation, use Copper wire with a minimum insulation temperature rating of 70°C, UL Class CC or Class J Fuses
 Data values shown in Italics are provisional
10.2.4. 500 – 600 Volt (+ / - 10%), 3 Phase Input, 3 Phase Output
Frame Power Rating
Size
kW HP
kW HP
2 0.75 1
2 1.5 2
2 2.2 3
2 4 5
2 5.5 7.5
3 7.5 10
3 11 15
3 15 20
4 18.5 25
4 22 30
4 30 40
5 37 50
5 45 60
6 55 75
6 75 100
6 90 125
6 110 175
Optidrive ODP-2 User Guide Revision 2.10
Input Fuse or MCB (Type B)
Current
A
Non UL UL
2.4 10 6
5.1 10 10
7.5 10 10
11.2 16 15
19 25 25
21 25 30
28.9 40 40
37.2 50 50
47 63 60
52.4 63 70
63.8 80 80
76.4 100 100
92.2 125 125
112.5 125 150
153.2 200 200
183.7 250 250
205.9 250 300
244.5 315 350
307.8 400 400
370 500 500
450 500 600
Input Fuse or MCB (Type B)
Current
A
Non UL UL
A Non UL UL
2.5 10 6
3.7 10 6
4.9 10 10
7.8 10 10
10.8 16 15
14.4 16 20
20.6 25 30
26.7 32 35
34 40 45
41.2 50 60
49.5 63 70
62.2 80 80
75.8 100 100
90.9 125 125
108.2 125 150
127.7 160 175
160 200 200
www.invertekdrives.com
Maximum Cable Size Rated
Output
Current
A
mm AWG/kcmil
8 8 2.2
8 8 4.1
8 8 5.8
8 8 9.5
8 8 14
8 8 18
8 8 24
16 5 30
16 5 39
16 5 46
35 2 61
35 2 72
150 300MCM 90
150 300MCM 110
150 300MCM 150
150 300MCM 180
150 300MCM 202
150 300MCM 240
150 300MCM 302
240 450MCM 370
240 450MCM 450
Maximum Cable Size Rated
Output
Current
A
mm AWG/kcmil
AWG /
mm kcmil A
8 8 2.1
8 8 3.1
8 8 4.1
8 8 6.5
8 8 9
8 8 12
8 8 17
8 8 22
16 5 28
16 5 34
16 5 43
35 2 54
35 2 65
150 300MCM 78
150 300MCM 105
150 300MCM 130
150 300MCM 150
Maximum Motor Cable Recommended
Length Brake
Resistance
m ft Ω
100 330 400
100 330 200
100 330 150
100 330 100
100 330 75
100 330 50
100 330 40
100 330 22
100 330 22
100 330 22
100 330 12
100 330 12
100 330 6
100 330 6
100 330 6
100 330 6
100 330 6
100 330 6
100 330 6
100 330 2
100 330 2
Maximum Motor Cable Recommended
Length Brake
Resistance
m ft Ω
m ft Ω
100 330 600
100 330 300
100 330 200
100 330 150
100 330 100
100 330 80
100 330 50
100 330 33
100 330 33
100 330 22
100 330 16
100 330 16
100 330 12
100 330 12
100 330 8
100 330 8
100 330 8
