3.4.2. IP55 Units
Drive A B
Size mm in mm
4 450 17.72 428 16.85
5 540 21.26 515 20.28
6 865 34.06 830 32.68
7 1280 50.39 1245 49.02
Optidrive ODP-2 User Guide Revision 2.10
C D
in mm in mm in
433 17.05 8 0.31
520 20.47 8 0.31
840 33.07 10 0.39
1255 49.41 10 0.39
Mounting Bolts
Frame Size Metric UNF
4 M8 #8
5 M8 #8
6 M10 5/16
7 M10 5/16
www.invertekdrives.com
E F
mm in mm in mm
252 9.92 171 6.73 110
270 10.63 235 9.25 175
330 12.99 330 12.99 200
360 14.17 330 12.99 200
Tightening Torques
Frame Size
Control Terminals All
Power Terminals 4
5
6
7
G H I
in mm in mm
4.33 4.25 0.17 7.5
6.89 4.25 0.17 7.5
7.87 5.5 0.22 11
7.87 5.5 0.22 11
Required Torque
0.5 Nm 4.5 lb-in
2 Nm 18 lb-in
4 Nm 35.5 lb-in
15 Nm 11 lb-ft
15 Nm 11 lb-ft
Weight
in kg lb
0.30 11.5 25.4
0.30 23 50.7
0.43 55 121.2
0.43 89 196.2
