SnapSAN S2000 User Guide
Select the initiator you want to add from the drop-down list labeled IQN. The list
shows the IQNs of all the initiators known to the appliance. If the initiator you want to
add is not listed, you can add it using the Initiators view (see
page 7-40).
If CHAP is enabled, specify the target's secret and, if you are using mutual CHAP, the
initiator's secret. Secrets must be between 24 and 32 hexadecimal digits long. Click
the Format Secrets as ASCII box to use ASCII characters rather than hexadecimal
digits. ASCII secrets must be between 12 and 16 characters long. The secrets entered
in this dialog box must be the same as those entered for the initiator.
Edit ACL. To change the access type of an initiator and alter its CHAP secrets, select
its IQN from the ACL and then click the Edit button (or select Edit ACL from the
SnapSAN Target Tasks list.)
NOTE: Before changing the ACL for a target that is being managed by the local iSCSI
If the local initiator is listed in the target's ACL, selecting Enable CHAP from the
SnapSAN Target Tasks list will log the initiator out of the target, automatically assign
a CHAP secret to the target, and log back into the target with that secret.
Remove ACL. To remove a selected initiator from the ACL, select its IQN from the
ACL and then click the Remove button (or select Remove ACL from the SnapSAN
Target Tasks list).
10400277-004 07/2011
initiator, the initiator must be logged out. The ACL modification dialog box pops up to
warn you to save any data before continuing.
©2010-11 Overland Storage, Inc.
"Initiators Category" on
7-13
