Datamax I-class series Operator's Manual page 68

Advanced Entry Calibration (continued)
Step Action
a) Place the media in the
sensor. Record the
reading and label it "P"
(paper).
b) Place the backing, notch,
or mark in the sensor.
14
Record the reading and
label it "G" or "M" (Gap or
Mark).
c) Remove media. Record
the reading and label it
"E" (Empty).
Press the
15
then press the
Press the
Using the
Key, set the Paper
Sensor Level to the value
determined in the previous
step.
16
Press the
select the entry and
advance the menu.
Repeat for the Gap Sensor
Level (or Mark Sensor Level)
and the Empty Sensor Level
entries.
I-Class
Displayed Message
GAIN TRAN
*08
Or, for reflective media:
GAIN REFL
*08
Key, and ADVANCED ENTRY
SENSOR LEVELS
Key.
PAPER SENSOR LEVEL
P*198 G*084 E*014
GAP SENSOR LEVEL
Key.
P*198 G*084 E*014
Key or the
EMPTY SENSOR LEVEL
P*198 G*084 E*014
Or, for reflective media:
Key to
PAPER SENSOR LEVEL
P*015 M*181 E*213
MARK SENSOR LEVEL
P*015 M*181 E*213
EMPTY SENSOR LEVEL
P*015 M*181 E*213
<yyy>
<0 - 31>
The samplings using the
selected Gain Number
are taken.
<yyy>
<0 - 31>
The sensor readings
must be entered into the
printer.


Selection is denoted by
an asterisk (*).
The displayed message
will change and the
selection will flash to
indicate the next entry.


Comment
