Datamax I-class series Operator's Manual page 35

Printer Options (continued)
Menu Item
START OF PRINT
ACTIVE HIGH
EDGE
LOW PULSE
HIGH PULSE
ACTIVE LOW
END OF PRINT
LOW PULSE
HIGH PULSE
ACTIVE LOW
ACTIVE HIGH
RIBBON LOW
ACTIVE LOW
ACTIVE HIGH
SLEW ENABLE
STANDARD
LOW PULSE
HIGH PULSE
ACTIVE LOW
ACTIVE HIGH
I-Class
Selects the type of input signal required to initiate
printing, where:
Triggers printing with a high signal.
Triggers printing with a signal edge transition.
Triggers printing with a low pulse.
Triggers printing with a high pulse.
Triggers printing with a low signal.
Sets the type of output signal generated to indicate End
of Print (EOP), where:
Outputs a low pulse upon completion.
Outputs a high pulse upon completion.
Outputs a logic low upon completion.
Outputs a logic high upon completion.
Sets the low ribbon signal (as determined by RIBBON
LOW OPTIONS; see Section 4.2.2), where:
Outputs a logic low when the roll reaches the setting.
Outputs a logic high when the roll reaches the setting.
Selects the type of input signal required to initiate label
slew, where:
Triggers slew with a low signal.
Triggers slew with a low pulse.
Triggers slew with a high pulse.
Triggers slew with a low signal.
Triggers slew with a high signal.
Details
