Datamax I-class series Operator's Manual page 19

4
Using the Control Panel
4.1 Operation
The Control Panel is composed of a display, indicators, and mode-dependant keys for easy
access to printer functions.
4.1.1 Display and Indicator Lights

Liquid Crystal Display (LCD)
The LCD provides textual information:
Following initialization, the READY message;
•
The time and date;
•
Label counts during batch jobs;
•
When in Menu Mode, the System Menu; and,
•
Displayed Messages.
•

The Ready Light provides operational state information:
ON indicates Ready Mode;
•
SLOW FLASHING indicates Menu Mode; and,
•
FAST FLASHING indicates data reception.
•

The Stop Light indicates a paused condition.

The Error Light indicates the following conditions (see Section 6.1.2):
SLOW FLASHING indicates a Warning; and,
•
FAST FLASHING indicates a Fault.
•

The MENU Key, when pressed and held, adjusts the LCD Contrast.
I-Class
2 3 4
STOP ERROR
READY
REV FWD
ENT
ESC
5
1
