4.3 The Test Menu
The TEST Key accesses six resident format selections that are printed at selected heat and
speed settings (see Section 4.1.4 for printing details).
Notes: (1) With the exception of the Configuration Label, all test labels require full

width media to capture the entire format.
(2) During a test, press the
(3) Use PRINT TEST RATE (Section 4.2.7) to delay printing.
4.3.1 Print Quality Label
The Print Quality Label can be used to ensure conformance
and visual aesthetics.
4.3.2 Configuration Label
The Configuration Label provides database information, as
detailed in Section 4.2.
Notes: (1) Label contents vary with application

version, model, and options.
(2) Use at least 2 inch (51mm) wide media and
set the Label Width accordingly (see
Section 4.2.2).
(3) Bulleted items indicate host changes not
yet saved.
Key or the Key to stop printing.
CONFIGURATION
TUE 09 09 AM 29JUL2008
PRINTER KEY
308-TB10-020312-001
APPLICATION VERSION
83-228 -11E 11.05
MCL Version 1.20.02-126
BOOT LOADER
83-2269-11A 11.01 10/02/2007
UNLOCKED
*NONE
FPGA
*
MACO
NOT SET
MACR
00-90-c9-01-d0-8
SYSTEM INFORMATION
PRINT BUFFER SIZE
100 in.
FLASH SIZE
2 MB
RAM TEST
PASS
OPTIONAL LANGUAGES
FRANCIAS.DLN
ITALIANO.DLN
DEUTSCH.DLN
ESPANOL.DL
ONF
COMMUNICATIONS
SERIAL PORT A
BAUD RATE
9600 BPS
PROTOCOL
BOTH
07/07/2008
PARITY
NONE
DATA BITS
8
STOP BITS
1
SERIAL PORT B
NOT INSTALLED
SERIAL PORT C
NOT INSTALLED
SERIAL PORT D
NOT INSTALLED
USB PORT
NOT INSTALLED
PARALLEL PORT A
PORT DIRECTION
UNI-DIRECTIONAL
PARALLEL PORT A
NOT INSTALLED
I-Class
