Installation Instructions - Altronix AL400ULX Installation Manual

Stand-by Specifications (total current shown):
Output
12VDC / 40AH Battery
24VDC / 12AH Battery
24VDC / 40AH Battery
Wiring methods shall be in accordance with the National Electrical Code/NFPA 70/NFPA 72/ANSI, and with all local
codes and authorities having jurisdiction. Product is intended for indoor use only.
1. Mount unit in the desired location. Mark and predrill holes in the wall to line up with the top two keyholes in the
enclosure. Install two upper fasteners and screws in the wall with the screw heads protruding. Place the enclosure's
upper keyholes over the two upper screws; level and secure. Mark the position of the lower two holes. Remove the
enclosure. Drill the lower holes and install two fasteners. Place the enclosure's upper keyholes over the two
upper screws. Install the two lower screws and make sure to tighten all screws (Enclosure Dimensions, pg. 7-8).
Fig. 1
Door
Fig. 1a
Wire
Strap
(from
Enclosure
to Door)
Bat Fail NC C NO NC C NO AC Fail
Battery & AC Supervision
Circuit
(power-limited)
Battery & AC
Supervision
Circuit
Fig. 1b
(power limited)
AC Delay
Fig. 1c
SW1
OFF - 24V
ON - 12V
AL400ULX series
4 hr. of Stand-by and
5 Minutes of Alarm
Stand-by = 4.0A
Alarm = 4.0A
- - - - - - - -
Stand-by = 3.0A
Alarm = 3.0A

Installation Instructions:

CAUTION: De-energize unit prior to servicing. For continued protection against risk
of electric shock and fire hazard replace fuse with the same type and rating.
Do not expose to rain or moisture.
Green
Lead
115VAC
power mains
non-power
limited
Class 1
AC Delay
+
12VDC Rechargeable Battery
(optional)
For 12VDC Operation
use hook-up in the
inset on the right
CAUTION: When power supply board is set for 12VDC use only one (1) 12VDC
stand-by battery.
Keep power limited wiring separate from non-power limited. Use minimum 0.25" spacing.
24 hr. of Stand-by and
5 Minutes of Alarm
Stand-by = 1.0A
Alarm = 4.0A
Stand-by = 200mA
Alarm = 3.0A
Stand-by = 1.0A
Alarm = 3.0A
Switch Position:
24VDC = SW1 OFF
12VDC = SW1 ON
ON
15
1
+
BAT ---
DC ---
60 hr. of Stand-by and
5 Minutes of Alarm
Stand-by = 300mA
Alarm = 4.0A
Stand-by = 300mA
Alarm = 3.0A
Power
Distribution
Module(s)
Divider
power limited
Battery connection (non power limited)
-
12VDC Rechargeable Battery
(optional)
- - - - - - - -
- 3 -
