Altronix AL400XB2V Manual

The AL400XB2V is a power supply/charger that converts a 220VAC (working range 198VAC - 256VAC), 50/60Hz
input into a 12VDC or 24VDC output (see specifications).
Input:
• Input 220VAC (working range 198VAC - 256VAC),
50/60Hz, 1.5A.
Output Rating:
• 12VDC or 24VDC selectable output.
• 12VDC @ 4A or 24VDC @ 3A continuous
supply current.
• Filtered and electronically regulated output.
Battery Backup:
• Built-in charger for sealed lead acid or gel type batteries.
• Maximum charge current 0.7A.
• Automatic switch over to stand-by battery when AC fails.
Power Supply Voltage Output Selections:
Output Switch Position
12VDC SW1 - ON (Fig. 1, on right)
24VDC SW1 - OFF (Fig. 1, on right)
Output
12VDC / 40AH Battery
24VDC / 12AH Battery
24VDC / 40AH Battery
The AL400XB2V should be installed in accordance with article 760 of The National Electrical Code or NFPA 72,
as well as all applicable Local Codes.
1. Mount the AL400XB2V in the desired location/enclosure.
2. Set the AL400XB2V to the desired DC output voltage by setting SW1 (Fig. 2, pg. 2) to the appropriate position
(refer to Power Supply Voltage Output Selections chart).
3. Connect AC power (220VAC 50/60Hz) to the terminals marked [L, G, N] (Fig. 2, pg. 2). Use 18 AWG or larger for
all power connections (Battery, DC output, AC input). Use 22 AWG to 18 AWG for power-limited circuits
(AC Fail/Low Battery reporting).
Keep power-limited wiring separate from non power-limited wiring (220VAC / 60Hz Input, Battery Wires).
Minimum 0.25" spacing must be provided.
CAUTION: Do not touch exposed metal parts. Shut branch circuit power before installing or servicing equipment.
There are no user serviceable parts on board. Refer installation and servicing to qualified service personnel.
4. Connect devices to be powered to the terminals marked [+ DC –] (Fig. 2, pg. 2).
5. Measure output voltage before connecting devices. This helps avoiding potential damage.
6. For Access Control applications batteries are optional. When batteries are not used, a loss of AC will result in the
loss of output voltage. When the use of stand-by batteries is desired, they must be lead acid or gel type.
Connect battery to the terminals marked [+ BAT –] (Fig. 2, pg. 2). Use two (2) 12VDC batteries connected in series
for 24VDC operation (battery leads included).
7. Connect appropriate signaling notification devices to AC FAIL & BAT FAIL (Fig. 2, pg. 2) supervisory relay outputs.
Note: When used in fire alarm, burglar alarm or access control applications, "AC Fail" relay should be utilized to
visually indicate that AC power is on. To delay report for 6 hours cut "AC Delay" jumper (Fig. 2a, pg. 2).
AL400XB2V
Power Supply/Charger

Overview:

Specifications:

OFF - 24V
ON - 12V
Stand-by Specifications:
4 hr. of Stand-by and
5 Minutes of Alarm
Stand-by = 4.0A
Alarm = 4.0A
- - - - - - - ­
Stand-by = 3.0A
Alarm = 3.0A

Installation Instructions:

Available from A1 Security Cameras
www.a1securitycameras.com email: sales@a1securitycameras.com
Battery Backup (cont'd):
• Zero voltage drop when switched over to battery backup.
Visual Indicators:
• AC input, DC output and Battery LED indicators.
Supervision:
• AC fail supervision (form "C" contacts).
• Low battery and battery presence supervision
(form "C" contacts).
Additional Features:
• Short circuit and thermal overload protection.
Board Dimensions (W x L x H approximate):
4.5" x 7.1" x 1.44" (114.3mm x 180.3mm x 36.6mm).
Fig. 1
OFF - 24V
ON - 12V
24 hr. of Stand-by and
5 Minutes of Alarm
Stand-by = 1.0A
Alarm = 4.0A
Stand-by = 200mA
Alarm = 3.0A
Stand-by = 1.0A
Alarm = 3.0A
SW1
60 hr. of Stand-by and
5 Minutes of Alarm
Stand-by = 300mA
Alarm = 4.0A
- - - - - - - ­
Stand-by = 300mA
Alarm = 3.0A
